| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.28, 57.9 |
| Conventional Or Drum In Hat Type Rotor | Drum-in-hat |
| Directional Or Non Directional Brake Surface | Non-directional |
| Discard Thickness | 0.33, 8.4 |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 211.3, 8.319 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 100.1, 3.94 |
| Mounting Bolt Hole Diameter | 0.507, 12.9 |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.39, 9.9 |
| Overall Height | 2.5, 63.5 |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| 2.5i | Wagon | 2014 | H4 2.5L | AWD Automatic |
| 2.5i | Wagon | 2010 - 2014 | H4 2.5L | AWD Automatic CVT & Manual |
| 2.5i Convenience | Wagon | 2014 | H4 2.5L | AWD Manual |
| 2.5i Convenience | Wagon | 2013 - 2014 | H4 2.5L | AWD Automatic CVT |
| 2.5i Limited | Wagon | 2010 - 2014 | H4 2.5L | AWD Automatic CVT |
| 2.5i Premium | Wagon | 2010 - 2014 | H4 2.5L | AWD Automatic CVT & Manual |
| 2.5i Sport | Wagon | 2010 | H4 2.5L | AWD Automatic CVT & Manual |
| 2.5i Touring | Wagon | 2012 - 2014 | H4 2.5L | AWD Automatic CVT & Manual |
| 3.6R | Wagon | 2010 - 2014 | H6 3.6L | AWD Automatic |
| 3.6R Limited | Wagon | 2010 - 2014 | H6 3.6L | AWD Automatic |
| 3.6R Premium | Wagon | 2010 - 2012 | H6 3.6L | AWD Automatic |
| Base | Wagon | 2010 - 2013 | H4 2.5L | AWD Automatic |
| Base | Wagon | 2010 - 2013 | H6 3.6L | AWD Automatic |
| Limited | Wagon | 2010 - 2014 | H4 2.5L | AWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Advance Auto Parts | 248479 |
| Advance Auto Parts | YH145207 |
| Advance Auto Parts | YH248479 |
| Advance Auto Parts | YH248479C |
| Advance Auto Parts | YH248479P |
| Autopartsource | 477380 |
| Autopartsource | 577380 |
| Autoxtra | AX900826 |
| AutoZone | 44615 |
| AutoZone | 44615DG |
| Bendix | PRT5811 |
| Bosch | 48011477 |
| BrakeBest | 980634 |
| BrakeBest | 980634FZN |
| BrakeBest | 980634PER |
| BrakeBest | 980634R |
| BrakeBest | 980634RGS |
| Casting Numbers | 326405 |
| Centric Parts | 120.47029 |
| Centric Parts | 121.47029 |
| Centric Parts | 126.47029CSL |
| Centric Parts | 126.47029CSR |
| Centric Parts | 126.47029SL |
| Centric Parts | 126.47029SR |
| Centric Parts | 127.47029CL |
| Centric Parts | 127.47029CR |
| Centric Parts | 127.47029L |
| Centric Parts | 127.47029R |
| Centric Parts | 128.47029CL |
| Centric Parts | 128.47029CR |
| Centric Parts | 128.47029L |
| Centric Parts | 128.47029R |
| Centric Parts | 227.47029L |
| Centric Parts | 227.47029R |
| Centric Parts | 320.47029 |
| Centric Parts | 321.47029 |
| Dura Corp | BR31509 |
| Dura Corp | BR900826 |
| Dura Corp | BR900826-02 |
| Dura Corp | BR90082602 |
| Dynamic Friction Company | 604-13021 |
| NAPA BRAKES | SDK6594 |
| NAPA BRAKES | TSR9659 |
| Newtek Automotive USA | 31509 |
| Parts Master | 900826 |
| PowerStop | JBR1365EVC |
| Promax | 14-31509 |
| Promax | 20-31509 |
| Subaru | 26700AJ00A |
| Subaru | 26700FG000 |
| UAP | 2900826 |
| UAP | R47029 |
| Wagner Brake | BD180203 |
| Wagner Brake | BD180203E |
| Winhere | 661898 |
Fits Years: 2010 2011 2012 2013 2014
Fits Models: Outback
