| Attribute | Value |
|---|---|
| Active Or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Damping | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Air Adjustable | No |
| Air Ride Suspension | No |
| Bearing Plate Included | No |
| Bladder Heavy Duty Crimping Rings Included | No |
| Bladder Sleeve(s) Included | No |
| Bladder(s) Included | No |
| Body Color | White |
| Body Diameter | 2.252, 57.2 |
| Body Material | Steel |
| Boot Included | Yes |
| Coil Over Springs Included | No |
| Coil Spring Insulator(s) Included | No |
| Compressed Length | 14.04, 356.6 |
| Cylinder Color | White |
| Cylinder Finish | Painted |
| Cylinder Material | Steel |
| Cylinder Outside Diameter | 2.252, 57.2 |
| Dust Shield Color | Red |
| Dust Shield Diameter | 2.99, 75.946 |
| Dust Shield Included | Yes |
| Dust Shield Material | Rubber |
| Extended Length | 22.11, 561.6 |
| Gas Charged | Yes |
| Grade Type | Performance |
| Hydraulic Lockout | No |
| Includes Bump Stop | No |
| Internal Construction Type | Twin Tube |
| Internal Rebound Bumper | Yes |
| Internal Rebound Spring | No |
| Lower Mount Code | Ls68 |
| Lower Mount Type | Loop Bushing And Sleeve Mount - 3/4" Sleeve Id X 1.7/8" Sleeve Oal |
| Maximum Ride Height Lowering Distance | 0 |
| Maximum Ride Height Raising Distance | 0 |
| Mounting Hardware Included | Yes |
| Parts Pack(s) | P01167 |
| Remote Reservoir | No |
| Rod Diameter | 0.622, 15.8 |
| Self Leveling | No |
| Shaft Material | Nitrocarburized |
| Shock Absorber Body End Measuring Point | Base Of Stem |
| Shock Absorber Bore Size | 1.3779527559055118, 35 |
| Shock Absorber Rod End Measuring Point | Center Of Loop |
| Shock Stroke | 205, 8.07 |
| Spring Included | No |
| Spring Isolators Included | No |
| Spring Seat Included | No |
| Strut Mount Insulator(s) Included | No |
| Travel Length | 205, 8.07 |
| Upper Mount Code | S5 |
| Upper Mount Type | Stem Mount - 2.5/8" Stem Length X 1/2"-13 Thread Pitch |
| Valving Type | Progressive |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| 40th Anniversary Edition | SUV | 2023 | V6 4.0L | RWD/4WD Automatic |
| Base | SUV | 2017 - 2018, 2020 - 2021 | V6 4.0L | 4WD Automatic |
| Limited | SUV | 2003 - 2023 | V6 4.0L | RWD/4WD Automatic |
| Limited | SUV | 2003 - 2009 | V8 4.7L | RWD/4WD Automatic |
| Nightshade | SUV | 2020 - 2022 | V6 4.0L | 4WD Automatic |
| Nightshade | SUV | 2020 - 2021 | V6 4.0L | RWD Automatic |
| SR5 | SUV | 2010 | L4 2.7L | RWD/4WD Automatic |
| SR5 | SUV | 2003 - 2023 | V6 4.0L | RWD/4WD Automatic |
| SR5 | SUV | 2003 - 2009 | V8 4.7L | RWD/4WD Automatic |
| SR5 Premium | SUV | 2018 - 2023 | V6 4.0L | RWD/4WD Automatic |
| Sport | SUV | 2003 - 2009 | V6 4.0L | RWD/4WD Automatic |
| Sport | SUV | 2003 - 2009 | V8 4.7L | RWD/4WD Automatic |
| TRD Off-Road | SUV | 2017 - 2023 | V6 4.0L | 4WD Automatic |
| TRD Off-Road Premium | SUV | 2018 - 2023 | V6 4.0L | 4WD Automatic |
| TRD Pro | SUV | 2015 - 2023 | V6 4.0L | 4WD Automatic |
| TRD Sport | SUV | 2022 - 2023 | V6 4.0L | RWD/4WD Automatic |
| Trail | SUV | 2021 - 2022 | V6 4.0L | RWD Automatic |
| Trail | SUV | 2010 - 2016, 2021 - 2022 | V6 4.0L | 4WD Automatic |
| Venture | SUV | 2020 - 2022 | V6 4.0L | 4WD Automatic |
We offer fast, reliable shipping on all orders:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
We want you to be 100% satisfied with your purchase. That's why we offer:
| Brand | Part Number |
|---|---|
| AutoZone | TS3432342B |
| AutoZone | TS3432552B |
| AutoZone | TS3433392B |
| AutoZone | TS3433692B |
| FCS | 341532 |
| Gabriel | G63885 |
| Gabriel | G64029 |
| Gabriel | G64030 |
| KYB | 344410 |
| KYB | 349185 |
| Monroe Shocks & Struts | 37270 |
| Rancho | RS5397 |
| Sensen | 12140464 |
| Toyota | 4853035160 |
| Toyota | 4853080605 |
| Toyota | 4853080607 |
| Toyota | 4853080608 |
| Toyota | 48530OW040 |
| Unity Automotive | 254030 |
Fits Years: 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 2022 2023
Fits Models: 4Runner
