| Attribute | Value |
|---|---|
| Belt Type | Serpentine |
| Clutch Included | Included |
| Coil Clock | 1 Wire Lead |
| Coil Type | Coil Less |
| Discharge Port Type | O-ring |
| Electronic Control Valve | Yes |
| Model | Pxv16 |
| Mount Distance B IN | 2.03 |
| Mount Distance B MM | 51.82 |
| Mount Distance IN | 1.000 |
| Mount Distance MM | 25.4 |
| Mounting Hardware? | Not Included |
| New Or Reman | Remanufactured |
| O Ring A Number/Desc | 24659 / Green O-ring |
| O Ring A Quantity | 1 |
| O Ring B Number/Desc | 24635 / Green Round O-ring |
| O Ring B Quantity | 1 |
| Oil Type | Pag 46 |
| Pulley Diameter B IN Secondary | 5.000 |
| Pulley Diameter B MM Secondary | 127 |
| Pulley Diameter IN | 4.375 |
| Pulley Diameter MM | 111.13 |
| Refrigerant Type | R134a |
| Suction Port Type | O-ring |
| Switch Type | N/a |
| Type | Sanden/sankyo |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| 2.5 | Hatchback | 2006 - 2008 | L5 2.5L | FWD Automatic & Manual |
| 2.5 | Hatchback | 2006 - 2008 | L5 2.5L | FWD Automatic & Manual |
| Comfortline | Hatchback | 2009 | L5 2.5L | FWD Automatic & Manual |
| Comfortline | Hatchback | 2009 | L5 2.5L | FWD Automatic & Manual |
| S | Hatchback | 2008 - 2009 | L5 2.5L | FWD Automatic & Manual |
| S | Hatchback | 2008 - 2009 | L5 2.5L | FWD Automatic & Manual |
| Trendline | Hatchback | 2009 | L5 2.5L | FWD Automatic & Manual |
| Trendline | Hatchback | 2009 | L5 2.5L | FWD Automatic & Manual |
We offer fast, reliable shipping on all orders:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
We want you to be 100% satisfied with your purchase. That's why we offer:
| Brand | Part Number |
|---|---|
| Reach Cooling | 7420666 |
| TCW | 317486T1 |
Fits Years: 2006 2007 2008 2009
Fits Models: Rabbit
