| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.68, 68.05 |
| Conventional Or Drum In Hat Type Rotor | Conventional |
| Directional Or Non Directional Brake Surface | Non-directional |
| Discard Thickness | 0.394 |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 107.95, 4.25 |
| Mounting Bolt Hole Diameter | 0.645, 16.4 |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.472 |
| Overall Height | 2.551, 64.8 |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| 2.5T | Sedan | 2004 - 2006 | L5 2.5L Turbo | FWD Automatic |
| 2.5T AWD | Sedan | 2004 - 2006 | L5 2.5L Turbo | AWD Automatic |
| 2.9 | Sedan | 1999 - 2004 | L6 2.9L | FWD Automatic |
| T6 | Sedan | 2002 - 2006 | L6 2.9L Turbo | FWD Automatic |
| T6 | Sedan | 1999 - 2003 | L6 2.8L Turbo | FWD Automatic |
| T6 Anniversary | Sedan | 2002 | L6 2.8L Turbo | FWD Automatic |
| T6 Executive | Sedan | 2000 - 2001 | L6 2.8L Turbo | FWD Automatic |
| T6 Premier | Sedan | 2005 | L6 2.9L Turbo | FWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Advance Auto Parts | N100086955ZIC |
| Advance Auto Parts | YH145409 |
| Advance Auto Parts | YH145409C |
| Advance Auto Parts | YH145409P |
| Autoxtra | 126218 |
| Autoxtra | 80980045 |
| Autoxtra | AX34206 |
| AutoZone | 34206DG |
| Bendix | 145409 |
| BrakeBest | 52011349 |
| BrakeBest | 980045 |
| BrakeBest | 980045FZN |
| BrakeBest | 980045R |
| BrakeBest | 980045RGS |
| Brembo | 08.7765.11 |
| Brembo | 25521 |
| Casting Numbers | 211401-C |
| Casting Numbers | 325618 |
| Centric Parts | 120.39025 |
| Centric Parts | 120.39036 |
| Centric Parts | 121.39025 |
| Centric Parts | 121.39036 |
| Centric Parts | 125.39025 |
| Centric Parts | 125.39025CRY |
| Centric Parts | 125.39036 |
| Centric Parts | 125.39036CRY |
| Centric Parts | 126.39025CSL |
| Centric Parts | 126.39025CSR |
| Centric Parts | 126.39025SL |
| Centric Parts | 126.39025SR |
| Centric Parts | 126.39036CSL |
| Centric Parts | 126.39036CSR |
| Centric Parts | 126.39036SL |
| Centric Parts | 126.39036SR |
| Centric Parts | 127.39025L |
| Centric Parts | 127.39025R |
| Centric Parts | 127.39036CL |
| Centric Parts | 127.39036CR |
| Centric Parts | 127.39036L |
| Centric Parts | 127.39036R |
| Centric Parts | 128.39025CL |
| Centric Parts | 128.39025CR |
| Centric Parts | 128.39025L |
| Centric Parts | 128.39025R |
| Centric Parts | 128.39036CL |
| Centric Parts | 128.39036CR |
| Centric Parts | 128.39036L |
| Centric Parts | 128.39036R |
| Centric Parts | 320.39025 |
| Centric Parts | 320.39025H |
| Centric Parts | 321.39025 |
| Continental-ContiTech | CW12151 |
| Dura Corp | BR34206 |
| Mighty Distributing System | 34206 |
| NAPA BRAKES | SDK6037 |
| Pilenga | 5263 |
| PowerStop | EBR634EVC |
| Promax | 14-34206 |
| Quinton Hazell | BDC4729 |
| TRW | 4066 |
| TRW | DF4066 |
| TRW | DF4066S |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X51614 |
| Volvo | 9434167 |
| Volvo | 94341670 |
| Volvo | 94341674 |
| WABCO - Archived | PS126218 |
| Wagner Brake | BD126218 |
| Wagner Brake | BD126218E |
| Winhere | 661409 |
Fits Years: 1999 2000 2001 2002 2003 2004 2005 2006
Fits Models: S80
