| Attribute | Value |
|---|---|
| 108.00 | |
| ABS Tone Ring Included | No |
| Assy/Disassy By Qualified Personnel Required! | . |
| Balancing Type | Mill Balancing |
| Bearings Included | No |
| Bolt Hole Circle Ø [in] | 4.25 |
| Bolt Hole Circle Ø [mm] | 108 |
| Brake Disc Thickness [in] | 0.47 |
| Brake Disc Type | Solid |
| California Proposition 65 Required | No |
| Center Hole Diameter | 108.0 |
| Centering Diameter [in] | 2.68 |
| Color | Silver |
| Colour | Silver |
| Construction | Full Cast |
| Directional Or Non Directional Brake Surface | Non-directional |
| Disc Finish | Coated |
| Discard Thickness | 10.00 |
| Grade Type | Standard Replacement |
| Hat Finish | Coated |
| Hole Arrangement / Number | 05/10 |
| Hole Arrangement/Number | 05/10 |
| Inner Diameter [in] | 7.01 |
| Inside Diameter | 68.0 |
| Machining | High-carbon |
| Material | Gray Cast Iron |
| Minimum Thickness [in] | 0.39 |
| Mounting Bolt Hole Circle Diameter | 108.00 |
| Nominal Thickness | 12.00 |
| Outer Diameter [in] | 11.30 |
| Overall Height | 64.80 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Solid |
| Surface | Coated |
| Surface Type | Smooth |
| Technical Information Number | 50284pro_hc_na |
| Weight [kg] | 5,4, 5.4 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| 2.5T | Sedan | 2004 - 2006 | L5 2.5L Turbo | FWD Automatic |
| 2.5T AWD | Sedan | 2004 - 2006 | L5 2.5L Turbo | AWD Automatic |
| 2.9 | Sedan | 1999 - 2004 | L6 2.9L | FWD Automatic |
| T6 | Sedan | 2002 - 2006 | L6 2.9L Turbo | FWD Automatic |
| T6 | Sedan | 1999 - 2003 | L6 2.8L Turbo | FWD Automatic |
| T6 Anniversary | Sedan | 2002 | L6 2.8L Turbo | FWD Automatic |
| T6 Executive | Sedan | 2000 - 2001 | L6 2.8L Turbo | FWD Automatic |
| T6 Premier | Sedan | 2005 | L6 2.9L Turbo | FWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| AISIN | V6R994S |
| Akebono | BN0312 |
| Akebono | BN0312E |
| AMC | FO2560 |
| Ashuki | P331027 |
| ATE | 24011201511 |
| ATE | 24031201511 |
| ATE | 412151 |
| ATE | 512151 |
| Bendix | 520929 |
| Bendix | 562174B |
| Bendix | 562174BC |
| Blue Print | ADF124333 |
| Borg & Beck | BBD4216 |
| Bosch | 0986478495 |
| Bosch | 0986479873 |
| Bosch | 0986AB5676 |
| Bosch | F026A06397 |
| Brake Engineering | DI955888 |
| Brembo | 08776510 |
| Brembo | 08776511 |
| Brembo | 08776514 |
| Brembo | 0877651X |
| Brembo | 08776575 |
| Cifam | 800562C |
| Delphi | BG3515 |
| Delphi | BG3515C |
| DON | PCD18062 |
| Dynamic Friction Company | 600-27024 |
| Dynamic Friction Company | 604-27024 |
| Dynamic Friction Company | 900-27024 |
| EBC Brakes | D963 |
| EBC Brakes | GD963 |
| EBC Brakes | USR963 |
| Febi-Bilstein | 18051 |
| Ferodo | DDF1079 |
| Ferodo | DDF10791 |
| Ferodo | DDF1079C |
| Ferodo | DDF1079C1 |
| Ferodo | DDF1079C1D |
| Ferodo | DDF1079X |
| FREMAX BRAKE ROTORS AND DRUMS | BD1674 |
| FTE | 9072189 |
| FTE | 9082102 |
| FTE | BS4729 |
| FTE | BS4729B |
| Girling | 6040664 |
| Hella Pagid | 50284PROHCNA |
| Hella Pagid | 8DD355107092 |
| Japan Parts | DP0321 |
| Japan Parts | DP0321C |
| JP Group A/S | 4963200500 |
| Jurid | 562174J |
| Jurid | 562174JC |
| Jurid | 562174JC1 |
| Key Parts | KBD4216 |
| LPR | V1487P |
| Mapco | 15967C |
| METELLI | 230562C |
| MEYLE | 5155230014PD |
| MEYLE | 5155235015PD |
| Mintex | MDC1434 |
| Mintex | MDC1434C |
| NK Autoparts | 204843 |
| NK Autoparts | 314843 |
| NK Autoparts | 344843 |
| Optimal | BS6340 |
| Optimal | BS6340C |
| PAGID Racing | 50284 |
| PAGID Racing | 50284PRO |
| Remsa | 662000 |
| SBS | 1815204843 |
| SBS | 1815314843 |
| SBS | 1815344843 |
| Textar | 92100700 |
| Textar | 92100703 |
| Textar | 92100705 |
| Textar | 98200100701 |
| TRW | DF4066 |
| TRW | DF7644 |
| TRW Steering and Suspension Parts | DF4066S |
| VAICO | V9540007 |
| Valeo | 186841 |
| Valeo | 672596 |
| Volvo | 31471821 |
| Volvo | 31471821-0 |
| Volvo | 9434167 |
| Volvo | 94341674 |
| Volvo | 94341674-0 |
| Volvo White | 94341670-0 |
| Zimmermann | 610370300 |
| Zimmermann | 610370320 |
| Zimmermann | 610370352 |
| Zimmermann | 610370370 |
| Zimmermann | 610370372 |
| Zimmermann | 610370375 |
Fits Years: 1999 2000 2001 2002 2003 2004 2005 2006
Fits Models: S80
