| Attribute | Value |
|---|---|
| 108.00 | |
| ABS Tone Ring Included | No |
| Assy/Disassy By Qualified Personnel Required! | . |
| Balancing Type | Mill Balancing |
| Bearings Included | No |
| Bolt Hole Circle Ø [in] | 4.25 |
| Bolt Hole Circle Ø [mm] | 108 |
| Bolt Hole Quantity | 6 |
| Brake Disc Thickness [in] | 1.10 |
| Brake Disc Thickness [mm] | 28 |
| Brake Disc Type | Internally Vented |
| California Proposition 65 Required | No |
| Center Hole Diameter | 108.0 |
| Color | Silver |
| Colour | Silver |
| Construction | Full Cast |
| Directional Or Non Directional Brake Surface | Non-directional |
| Disc Finish | Coated |
| Discard Thickness | 26.00 |
| Grade Type | Standard Replacement |
| Hat Finish | Coated |
| Hole Arrangement / Number | 05/06 |
| Hole Arrangement/Number | 05/06 |
| Inner Diameter [in] | 5.51 |
| Inside Diameter | 63.6 |
| Machining | High-carbon |
| Material | Gray Cast Iron |
| Minimum Thickness [in] | 1.02 |
| Minimum Thickness [mm] | 26 |
| Mounting Bolt Hole Circle Diameter | 108.00 |
| Mounting Bolt Hole Quantity | 6 |
| Nominal Thickness | 28.00 |
| Number Of Bolts/screws | 1 |
| Outer Diameter [in] | 11.81 |
| Overall Height | 52.10 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Vented |
| Surface | Coated |
| Surface Type | Smooth |
| Technical Information Number | 54592pro_hc_na |
| Weight [kg] | 8,8, 8.8 |
| Wheel Bolt Bore Diameter [mm] | 15.8 |
| Wheel Bolt Bore Ø [mm] | 15,8, 15.8 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| 3.2 | Sedan | 2007 - 2014 | L6 3.2L | FWD Automatic |
| Addition | Sedan | 2011 | L6 3.0L Turbo | AWD Automatic |
| Base | Sedan | 2012 - 2013 | L4 2.0L Turbo | FWD Manual |
| Base | Sedan | 2010 | L6 3.0L Turbo | AWD Automatic |
| Base | Sedan | 2010 | V8 4.4L | AWD Automatic |
| Evolution | Sedan | 2013 | L4 2.0L Turbo | FWD Manual |
| Kinetic | Sedan | 2011 | L6 3.0L Turbo | AWD Automatic |
| Luxury | Sedan | 2014 - 2015 | L6 3.0L Turbo | AWD Automatic |
| T5 | Sedan | 2015 - 2016 | L4 2.0L Turbo | FWD Automatic |
| T5 Platinum | Sedan | 2016 | L4 2.0L Turbo | FWD Automatic |
| T6 | Sedan | 2008 - 2015 | L6 3.0L Turbo | AWD Automatic |
| T6 | Sedan | 2008 - 2009 | L6 3.2L | FWD Automatic |
| V8 | Sedan | 2007 - 2010 | V8 4.4L | AWD Automatic |
| V8 | Sedan | 2007 - 2009 | V8 4.4L | FWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| ADVICS | Z6F671WS |
| AISIN | Z6F671S |
| Akebono | BN0126 |
| Akebono | BN0126E |
| AMC | FO2700 |
| Ashuki | P330113 |
| ATE | 24012801541 |
| ATE | 24032801541 |
| ATE | 428154 |
| Bendix | 521472 |
| Bendix | 562363B |
| Bendix | 562624BC |
| Bendix | 562628BC |
| Blue Print | ADF124305 |
| Borg & Beck | BBD4567 |
| Bosch | 0986479261 |
| Bosch | 0986479974 |
| Bosch | 0986T16767 |
| Bosch | BD1139 |
| Brake Engineering | DI956625 |
| Brake Engineering | DI956929 |
| Brembo | 09A42710 |
| Brembo | 09A42711 |
| Brembo | 09A42714 |
| Brembo | 09A4271X |
| Brembo | 09A42731 |
| Brembo | 09A4273E |
| Brembo | 59E11504 |
| Brembo | FD214000 |
| Cifam | 800896C |
| Delphi | BG4094 |
| Delphi | BG4094C |
| Delphi | BG4094C18B1 |
| Delphi | BG4094C19B1 |
| DON | PCD10542 |
| Dynamic Friction Company | 600-27041 |
| Dynamic Friction Company | 604-27041 |
| Dynamic Friction Company | 900-27041 |
| EBC Brakes | D2054 |
| Febi-Bilstein | 28361 |
| Ferodo | DDF1567 |
| Ferodo | DDF15671 |
| Ferodo | DDF1567C |
| Ferodo | DDF1567CD |
| Ferodo | DDF1567X |
| FREMAX BRAKE ROTORS AND DRUMS | BD6765 |
| FTE | 9071006 |
| FTE | 9081221 |
| FTE | 9082582 |
| FTE | BS5562 |
| FTE | BS5562B |
| FTE | BS5562H |
| FTE | BS5562HB |
| Girling | 6048505 |
| Hella Pagid | 54592PROHCNA |
| Hella Pagid | 8DD355118832 |
| Japan Parts | DIL13 |
| Japan Parts | DIL13C |
| JP Group A/S | 1563102100 |
| Jurid | 562628JC |
| Jurid | 562628JC1 |
| Key Parts | KBD4452 |
| Land Rover | LR000571 |
| Land Rover | LR068925 |
| LPR | F1035V |
| LPR | F1035VR |
| Magneti Marelli | 360406087601 |
| Magneti Marelli | 360704033600 |
| Magneti Marelli | 361302040118 |
| METELLI | 230896C |
| MEYLE | 7155210026PD |
| MEYLE | 7835210026PD |
| Mintex | MDC1809 |
| Mintex | MDC1809C |
| Mintex | MDC81809C |
| Mintex | MDK0234 |
| Mintex | MDK0235 |
| National | NBD1429 |
| NK Autoparts | 202573 |
| NK Autoparts | 202581 |
| NK Autoparts | 312573 |
| NK Autoparts | 312581 |
| Optimal | BS8256 |
| Optimal | BS8256C |
| Optimal | BS8256HC |
| PAGID Racing | 54592 |
| Pilenga | V259 |
| Quinton Hazell | BDC5562 |
| Remsa | 6101910 |
| SBS | 1815202573 |
| SBS | 1815312573 |
| SBS | 1815342573 |
| Textar | 92159200 |
| Textar | 92159203 |
| Textar | 92159205 |
| Textar | 98200159201 |
| Triscan | 812016148 |
| Trucktec | 2235100 |
| TRW | DF4850S |
| TRW Steering and Suspension Parts | DF4850SL |
| TRW Steering and Suspension Parts | DF4850SR |
| TRW Steering and Suspension Parts | DF4850XSS |
| Valeo | 196068 |
| Valeo | 196084 |
| Valeo | 197055 |
| Valeo | 672575 |
| Volvo | 30736311 |
| Volvo | 30736311-0 |
| Volvo | 30769056 |
| Volvo | 30769056-0 |
| Volvo | 31202327 |
| Volvo | 31202327-0 |
| Volvo | 31202331 |
| Volvo | 31341382 |
| Volvo | 31358885 |
| Volvo | 31358885-0 |
| Wagner | WGR15671 |
| Zimmermann | 250136000 |
| Zimmermann | 250136020 |
| Zimmermann | 250136052 |
| Zimmermann | 250136053 |
| Zimmermann | 250136070 |
| Zimmermann | 250136072 |
| Zimmermann | 250136075 |
Fits Years: 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016
Fits Models: S80
