| Attribute | Value |
|---|---|
| 120.00 | |
| ABS Tone Ring Included | No |
| Assy/Disassy By Qualified Personnel Required! | . |
| Balancing Type | Mill Balancing |
| Bearings Included | No |
| Bolt Hole Circle Ø [in] | 4.72 |
| Bolt Hole Circle Ø [mm] | 120 |
| Bolt Hole Quantity | 6 |
| Brake Disc Thickness [in] | 0.79 |
| Brake Disc Thickness [mm] | 20 |
| Brake Disc Type | Internally Vented, Two-piece Brake Disc |
| California Proposition 65 Required | No |
| Center Hole Diameter | 120.0 |
| Centering Diameter [in] | 2.95 |
| Construction | Composite |
| Directional Or Non Directional Brake Surface | Non-directional |
| Disc Finish | Coated |
| Discard Thickness | 18.40 |
| Grade Type | Standard Replacement |
| Hat Finish | Coated |
| Hole Arrangement / Number | 05/06 |
| Hole Arrangement/Number | 05/06 |
| Inner Diameter [in] | 7.28 |
| Inside Diameter | 75.0 |
| Machining | High-carbon |
| Material | Gray Cast Iron & Alum Hat, Gray Cast Iron & Aluminium Hat |
| Minimum Thickness [mm] | 18,4, 18.4 |
| Mounting Bolt Hole Circle Diameter | 120.00 |
| Mounting Bolt Hole Quantity | 6 |
| Nominal Thickness | 20.00 |
| Number Of Bolts/screws | 2 |
| Outer Diameter [in] | 12.99 |
| Overall Height | 68.90 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Vented |
| Surface | Coated |
| Surface Type | Smooth |
| Technical Information Number | 65130pro_hc |
| Weight [kg] | 7,4, 7.4 |
| Wheel Bolt Bore Diameter [mm] | 16.5 |
| Wheel Bolt Bore Ø [mm] | 16.5 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Sedan | 2012 - 2016 | L4 2.0L Turbo | RWD Automatic |
| Base | Sedan | 2011 | L6 3.0L | RWD Automatic |
| Lujo | Sedan | 2011 | L6 3.0L | RWD Automatic |
| Luxury | Sedan | 2014 - 2016 | L4 2.0L Turbo | RWD Automatic |
| M Sport | Sedan | 2014 - 2016 | L4 2.0L Turbo | RWD Automatic |
| Top | Sedan | 2011 | L6 3.0L | RWD Automatic |
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Sedan | 2012 - 2016 | L4 2.0L Turbo | AWD Automatic |
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Sedan | 2014 - 2016 | L6 3.0L DIESEL Turbo | RWD Automatic |
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Sedan | 2014 - 2016 | L6 3.0L DIESEL Turbo | AWD Automatic |
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Sedan | 2011 - 2016 | L6 3.0L Turbo | RWD Automatic & Manual |
| Gran Turismo | Hatchback | 2011 - 2016 | L6 3.0L Turbo | RWD Automatic |
| Lujo | Sedan | 2013 | L6 3.0L Turbo | RWD Automatic |
| Luxury | Sedan | 2014 - 2016 | L6 3.0L Turbo | RWD Automatic |
| M Sport | Sedan | 2013 - 2016 | L6 3.0L Turbo | RWD Automatic |
| Top | Sedan | 2013 | L6 3.0L Turbo | RWD Automatic |
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Sedan | 2011 - 2016 | L6 3.0L Turbo | AWD Automatic |
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Sedan | 2012 - 2016 | L6 3.0L FULL HYBRID EV-GAS (FHEV) Turbo | RWD Automatic |
| M Sport | Sedan | 2014 - 2015 | L6 3.0L FULL HYBRID EV-GAS (FHEV) Turbo | RWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| ATE | 24012002292 |
| Bendix | BR9666EURO |
| BMW | 34 42 6 312 127 |
| BMW | 34 42 6 528 287 |
| BMW | 34 42 6 873 733 |
| BMW | 34216793127 |
| BMW | 34216898733 |
| BMW | 6 775 287 |
| BMW | 6 793 127 |
| BMW | 6898733 |
| Borg & Beck | BBD6040S |
| Bosch | 0986479D58 |
| Bosch | 0986479E04 |
| Brake Engineering | DI956895 |
| Brembo | 09C41113 |
| Delphi | BG4664C |
| Delphi | BG9421BC |
| Dynamic Friction Company | 600-31104 |
| Dynamic Friction Company | 604-31104 |
| Dynamic Friction Company | 900-31104 |
| Dynamic Friction Company | 900-31104A |
| EBC Brakes | D1817R |
| EBC Brakes | USR1817R |
| Febi-Bilstein | 104804 |
| Ferodo | DDF2504VC |
| FREMAX BRAKE ROTORS AND DRUMS | BD3558 |
| FTE | 9081303 |
| FTE | BS7847HB |
| Girling | 6066175 |
| Hella Pagid | 65130PROHC |
| Hella Pagid | 8DD355120671 |
| Japan Parts | DP0123 |
| Japan Parts | DP0123C |
| Jurid | 563156JVC |
| Jurid | 563156JVC1 |
| LPR | B2074V |
| LPR | B2074VBR |
| METELLI | 231281C |
| Mintex | MDCB2585 |
| NK Autoparts | 3415114 |
| NK Autoparts | 341595 |
| Optimal | BS9358 |
| Optimal | BS9358HC |
| PAGID Racing | 65130 |
| PAGID Racing | 65130HC |
| Pilenga | V477B1 |
| SBS | 18153415114 |
| SBS | 1815341595 |
| Textar | 92265925 |
| Textar | 98200265901 |
| TRW | DF6617S |
| VAICO | V2080086 |
| Zimmermann | 150348420 |
| Zimmermann | 150348432 |
| Zimmermann | 150348452 |
Fits Years: 2011 2012 2013 2014 2015 2016
Fits Models: 528i, 528i xDrive, 535d, 535d xDrive, 535i, 535i xDrive, ActiveHybrid 5
