| Attribute | Value |
|---|---|
| Center Electrode Core Material | Copper |
| Center Electrode Design | Fine Wire |
| Center Electrode Insulator Tip Projection | 0.16, 4.0 |
| Center Electrode Projection | Mid Projection |
| Center Electrode Tip Material | Iridium |
| Electrical Terminal Type | Non-removable Nut |
| Grade Type | Performance |
| Ground Configuration | J-gap |
| Ground Electrode Core Material | Nickel |
| Ground Electrode Quantity | 1 |
| Ground Electrode Tip Design | Taper Cut |
| Ground Electrode Tip Material | Nickel |
| Hex Size | 5/8" (16mm) |
| Insulator Height | 2.07, 52.5 |
| Insulator Material | Ceramic |
| Manufacturer Heat Range | 5 |
| Material Grade | Iridium |
| Part Number | Ur5ix |
| Pre Gap Size | .040, 1.0 |
| Reach | 0.460, 11.2 |
| Resistance | 5000.0 |
| Resistor Type | Yes |
| Seat Type | Tapered |
| Service Number | Ur5ix |
| Short Style Spark Plug | No |
| Skirt | No |
| Skirt Length | 0.0 |
| Stock Number | 7177 |
| Thread Diameter | 0.551, 14.0 |
| Washer Included | No |
This part fits the following vehicles:
This is a universal part that fits 5,963 vehicle configurations across 12 makes.
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
Fits Years: 1970 1971 1972 1973 1974 1975 1976 1977 1978 1979 1980 1981 1982 1983 1984 1985 1986 1987 1988 1989 1990 1991 1992 1993 1994 1995 1996 1997
