| Attribute | Value |
|---|---|
| 120.00 | |
| ABS Tone Ring Included | No |
| Assy/Disassy By Qualified Personnel Required! | . |
| Balancing Type | Mill Balancing |
| Bearings Included | No |
| Bolt Hole Circle Ø [in] | 4.72 |
| Bolt Hole Circle Ø [mm] | 120 |
| Bolt Hole Quantity | 6 |
| Brake Disc Thickness [in] | 0.79 |
| Brake Disc Thickness [mm] | 20 |
| Brake Disc Type | Internally Vented |
| California Proposition 65 Required | No |
| Center Hole Diameter | 120.0 |
| Color | Silver |
| Colour | Silver |
| Construction | Full Cast |
| Directional Or Non Directional Brake Surface | Non-directional |
| Disc Finish | Coated |
| Discard Thickness | 18.40 |
| Grade Type | Standard Replacement |
| Hat Finish | Coated |
| Hole Arrangement / Number | 05/06 |
| Hole Arrangement/Number | 05/06 |
| Inner Diameter [in] | 7.28 |
| Inside Diameter | 75.1 |
| Machining | High-carbon |
| Material | Gray Cast Iron |
| Minimum Thickness [mm] | 18,4, 18.4 |
| Mounting Bolt Hole Circle Diameter | 120.00 |
| Mounting Bolt Hole Quantity | 6 |
| Nominal Thickness | 20.00 |
| Number Of Bolts/screws | 1 |
| Outer Diameter [in] | 12.60 |
| Overall Height | 78.60 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Vented |
| Surface | Coated |
| Surface Type | Smooth |
| Technical Information Number | 54611pro_hc_na |
| Weight [kg] | 7,6, 7.6 |
| Wheel Bolt Bore Diameter [mm] | 16.7 |
| Wheel Bolt Bore Ø [mm] | 16.7 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| 3.0si | SUV | 2007 - 2009 | L6 3.0L | AWD Automatic |
| 4.8i | SUV | 2007 - 2008 | V8 4.8L | AWD Automatic |
| 4.8i Premium | SUV | 2007 - 2009 | V8 4.8L | AWD Automatic |
| Base | SUV | 2014 - 2015 | L6 3.0L Turbo | AWD Automatic |
| Excellence | SUV | 2014 - 2016 | L6 3.0L Turbo | AWD Automatic |
| Excellence | SUV | 2014 - 2016 | V8 4.4L Turbo | AWD Automatic |
| M | SUV | 2012 | L6 3.0L Turbo | AWD Automatic |
| M | SUV | 2011 | L6 3.0L | AWD Automatic |
| M | SUV | 2010 - 2018 | V8 4.4L Turbo | AWD Automatic |
| M Edition Black Fire | SUV | 2018 | V8 4.4L Turbo | AWD Automatic |
| M Sport | SUV | 2015 - 2016 | V8 4.4L Turbo | AWD Automatic |
| M Sport | SUV | 2014 - 2016 | L6 3.0L Turbo | AWD Automatic |
| sDrive35i | SUV | 2014 - 2018 | L6 3.0L Turbo | RWD Automatic |
| xDrive30i | SUV | 2011 - 2013 | L6 3.0L Turbo | AWD Automatic |
| xDrive30i | SUV | 2011 - 2013 | V8 4.4L Turbo | AWD Automatic |
| xDrive30i | SUV | 2009 - 2011 | L6 3.0L | AWD Automatic |
| xDrive30i M Sport | SUV | 2009 - 2010 | L6 3.0L | AWD Automatic |
| xDrive35d | SUV | 2009 - 2018 | L6 3.0L DIESEL Turbo | AWD Automatic |
| xDrive35i | SUV | 2011 | L6 3.0L | AWD Automatic |
| xDrive35i | SUV | 2011 - 2018 | L6 3.0L Turbo | AWD Automatic |
| xDrive35i | SUV | 2011 - 2013 | V8 4.4L Turbo | AWD Automatic |
| xDrive35i Excellence | SUV | 2017 - 2018 | L6 3.0L Turbo | AWD Automatic |
| xDrive35i M Sport | SUV | 2017 - 2018 | L6 3.0L Turbo | AWD Automatic |
| xDrive40e | SUV | 2016 - 2018 | L4 2.0L PLUG-IN HYBRID EV-GAS (PHEV) Turbo | AWD Automatic |
| xDrive40e Excellence | SUV | 2016 - 2018 | L4 2.0L PLUG-IN HYBRID EV-GAS (PHEV) Turbo | AWD Automatic |
| xDrive48i | SUV | 2009 - 2010 | V8 4.8L | AWD Automatic |
| xDrive48i M Sport | SUV | 2009 - 2010 | V8 4.8L | AWD Automatic |
| xDrive50i | SUV | 2011 - 2018 | V8 4.4L Turbo | AWD Automatic |
| xDrive50i Excellence | SUV | 2017 - 2018 | V8 4.4L Turbo | AWD Automatic |
| xDrive50i M Sport | SUV | 2017 - 2018 | V8 4.4L Turbo | AWD Automatic |
| xDrive50i Security | SUV | 2018 | V8 4.4L Turbo | AWD Automatic |
| xDrive50i Security Plus | SUV | 2018 | V8 4.4L Turbo | AWD Automatic |
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| ActiveHybrid | SUV | 2010 - 2011 | V8 4.4L FULL HYBRID EV-GAS (FHEV) Turbo | AWD Automatic |
| Base | SUV | 2015 | L6 3.0L Turbo | AWD Automatic |
| Extravagance | SUV | 2015 - 2016 | L6 3.0L Turbo | AWD Automatic |
| Extravagance | SUV | 2015 - 2016 | V8 4.4L Turbo | AWD Automatic |
| M | SUV | 2011 - 2013 | L6 3.0L Turbo | AWD Automatic |
| M | SUV | 2010 - 2019 | V8 4.4L Turbo | AWD Automatic |
| M Edition Black Fire | SUV | 2018 | V8 4.4L Turbo | AWD Automatic |
| M Sport | SUV | 2015 - 2016 | L6 3.0L Turbo | AWD Automatic |
| M Sport | SUV | 2015 - 2016 | V8 4.4L Turbo | AWD Automatic |
| sDrive35i | SUV | 2015 - 2019 | L6 3.0L Turbo | RWD Automatic |
| xDrive35i | SUV | 2009 - 2019 | L6 3.0L Turbo | AWD Automatic |
| xDrive35i Extravagance | SUV | 2017, 2019 | L6 3.0L Turbo | AWD Automatic |
| xDrive35i M Performance | SUV | 2013 | L6 3.0L Turbo | AWD Automatic |
| xDrive35i M Sport | SUV | 2017, 2019 | L6 3.0L Turbo | AWD Automatic |
| xDrive35iA | SUV | 2009 - 2010 | L6 3.0L Turbo | AWD Automatic |
| xDrive50i | SUV | 2009 - 2019 | V8 4.4L Turbo | AWD Automatic |
| xDrive50i Extravagance | SUV | 2017, 2019 | V8 4.4L Turbo | AWD Automatic |
| xDrive50i M Performance | SUV | 2013 | V8 4.4L Turbo | AWD Automatic |
| xDrive50i M Sport | SUV | 2017, 2019 | V8 4.4L Turbo | AWD Automatic |
| xDrive50iA | SUV | 2009 - 2010 | V8 4.4L Turbo | AWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Akebono | BN0411 |
| Akebono | BN0411E |
| AMC | FO4194 |
| ATE | 24012002061 |
| ATE | 420206 |
| Bendix | 521545 |
| Bendix | 562521BC |
| Bendix | BR2865ULT |
| Blue Print | ADB114304 |
| BMW | 34 21 6 868 940 |
| BMW | 34 42 6 197 970 |
| BMW | 34 42 6 324 247 |
| BMW | 34 42 6 647 479 |
| BMW | 34216868940 |
| BMW | 34216886479 |
| BMW | 6 771 970 |
| BMW | 6 793 247 |
| BMW | 6 868 940 |
| BMW | 6886479 |
| Borg & Beck | BBD4726 |
| Bosch | 0986479442 |
| Bosch | 0986AB5782 |
| Bosch | 0986T16782 |
| Bosch | F026A09382 |
| Brake Engineering | DI956593 |
| Brembo | 09992511 |
| Brembo | 0999251X |
| Brembo | 59E11472 |
| Cifam | 8001025C |
| Delphi | BG4168 |
| Delphi | BG4168C18B1 |
| Dynamic Friction Company | 600-31143 |
| Dynamic Friction Company | 604-31143 |
| Dynamic Friction Company | 900-31143 |
| EBC Brakes | D1524 |
| EBC Brakes | GD1524 |
| EBC Brakes | USR1524 |
| Febi-Bilstein | 36386 |
| Ferodo | DDF1715 |
| Ferodo | DDF17151 |
| Ferodo | DDF1715C |
| Ferodo | DDF1715C1 |
| Ferodo | DDF1715C1D |
| Ferodo | DDF1715DSL1D |
| Ferodo | DDF1715DSR1D |
| FREMAX BRAKE ROTORS AND DRUMS | BD1970 |
| FTE | 9071043 |
| FTE | 9081029 |
| FTE | 9082603 |
| FTE | BS7244 |
| FTE | BS7244B |
| FTE | BS7244HB |
| Girling | 6048545 |
| Hella Pagid | 54611PROHCNA |
| Hella Pagid | 8DD355114002 |
| Japan Parts | DP0129 |
| Japan Parts | DP0129C |
| JP Group A/S | 1463204800 |
| Jurid | 562521JC |
| Jurid | 562521JC1 |
| LPR | B2054V |
| LPR | B2054VR |
| Magneti Marelli | 360406068900 |
| Magneti Marelli | 360406178102 |
| Meritor | MBR5143 |
| METELLI | 231025C |
| MEYLE | 3155230024PD |
| Mintex | MDC2186 |
| Mintex | MDC82186C |
| Motaquip | LVBD1330 |
| National | NBD1527 |
| NK Autoparts | 201583 |
| NK Autoparts | 311583 |
| NK Autoparts | 341583 |
| Optimal | BS8278 |
| Optimal | BS8278C |
| PAGID Racing | 54611 |
| PAGID Racing | 54611PRO |
| Remsa | 6128710 |
| SBS | 1815201583 |
| SBS | 1815311583 |
| SBS | 1815341583 |
| Textar | 92161103 |
| Textar | 92161105 |
| Textar | 98200161101 |
| Topran | 502030 |
| Trucktec | 0834147 |
| TRW | DF4854S |
| TRW Steering and Suspension Parts | DF4854SL |
| TRW Steering and Suspension Parts | DF4854SR |
| TRW Steering and Suspension Parts | DF4854XSS |
| VAICO | V2080094 |
| Valeo | 197179 |
| Valeo | 297179 |
| Valeo | 672507 |
| Zimmermann | 150345020 |
| Zimmermann | 150345052 |
| Zimmermann | 150345053 |
Fits Years: 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019
Fits Models: X5, X6
