| Attribute | Value |
|---|---|
| 120.00 | |
| ABS Tone Ring Included | No |
| Assy/Disassy By Qualified Personnel Required! | . |
| Balancing Type | Mill Balancing |
| Bearings Included | No |
| Bolt Hole Circle Ø [in] | 4.72 |
| Bolt Hole Circle Ø [mm] | 120 |
| Bolt Hole Quantity | 6 |
| Brake Disc Thickness [in] | 1.18 |
| Brake Disc Thickness [mm] | 30 |
| Brake Disc Type | Internally Vented, Two-piece Brake Disc |
| California Proposition 65 Required | No |
| Center Hole Diameter | 120.0 |
| Centering Diameter [in] | 3.11 |
| Construction | Composite |
| Directional Or Non Directional Brake Surface | Non-directional |
| Disc Finish | Coated |
| Discard Thickness | 28.40 |
| Grade Type | Standard Replacement |
| Hat Finish | Coated |
| Hole Arrangement / Number | 05/06 |
| Hole Arrangement/Number | 05/06 |
| Inside Diameter | 79.0 |
| Machining | High-carbon |
| Material | Gray Cast Iron & Alum Hat, Gray Cast Iron & Aluminium Hat |
| Minimum Thickness [mm] | 28,4, 28.4 |
| Mounting Bolt Hole Circle Diameter | 120.00 |
| Mounting Bolt Hole Quantity | 6 |
| Nominal Thickness | 30.00 |
| Number Of Bolts/screws | 1 |
| Outer Diameter [in] | 13.70 |
| Overall Height | 77.10 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Vented |
| Surface | Coated |
| Surface Type | Smooth |
| Technical Information Number | 65155pro_hc |
| Weight [kg] | 11,5, 11.5 |
| Wheel Bolt Bore Diameter [mm] | 14.5 |
| Wheel Bolt Bore Ø [mm] | 14.5 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Sedan | 2008 - 2010 | L6 3.0L Turbo | RWD Automatic & Manual |
| Base | Wagon | 2010 | L6 3.0L Turbo | RWD Automatic & Manual |
| Gran Turismo | Hatchback | 2010 | L6 3.0L Turbo | RWD Automatic |
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Sedan | 2004 - 2005 | V8 4.4L | RWD Automatic & Manual |
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Active Dynamic | Sedan | 2010 | V8 4.8L | RWD Automatic & Manual |
| Base | Sedan | 2006 - 2010 | V8 4.8L | RWD Automatic & Manual |
| Formula 1 | Sedan | 2006 - 2009 | V8 4.8L | RWD Automatic & Manual |
| Top | Sedan | 2006 - 2009 | V8 4.8L | RWD Automatic & Manual |
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Convertible | 2004 - 2005 | V8 4.4L | RWD Automatic & Manual |
| Base | Coupe | 2004 - 2005 | V8 4.4L | RWD Automatic & Manual |
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Convertible | 2006 - 2010 | V8 4.8L | RWD Automatic & Manual |
| Base | Coupe | 2006 - 2010 | V8 4.8L | RWD Automatic & Manual |
We offer fast, reliable shipping on all orders:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
We want you to be 100% satisfied with your purchase. That's why we offer:
| Brand | Part Number |
|---|---|
| ATE | 24013001862 |
| ATE | 430186 |
| Bendix | 562401B |
| Bendix | 562401BC |
| Blue Print | ADB114385 |
| BMW | 34 41 6 382 824 |
| BMW | 6 763 824 |
| Borg & Beck | BBD4596 |
| Borg & Beck | BBD6031S |
| Bosch | 0986479584 |
| Bosch | 0986479E14 |
| Brake Engineering | DI956268S |
| Brake Engineering | DI956483S |
| Brembo | 09C41913 |
| Cifam | 800853C |
| Delphi | BG9163C |
| Delphi | BG9788 |
| Dynamic Friction Company | 600-31063 |
| Dynamic Friction Company | 604-31063 |
| Dynamic Friction Company | 900-31063 |
| Dynamic Friction Company | 900-31063A |
| EBC Brakes | D1390R |
| EBC Brakes | USR1390R |
| Febi-Bilstein | 105719 |
| Ferodo | DDF1701 |
| Ferodo | DDF17011 |
| Ferodo | DDF1701C |
| Ferodo | DDF1701C1 |
| FREMAX BRAKE ROTORS AND DRUMS | BD3402 |
| FTE | 9081323 |
| FTE | BS7226HB |
| Girling | 6066255 |
| Hella Pagid | 65155PROHC |
| Hella Pagid | 8DD355120981 |
| Japan Parts | DI0128 |
| Jurid | 562340J |
| Jurid | 562401J |
| Jurid | 563078JC1 |
| LPR | B2099VBR |
| METELLI | 230853C |
| MEYLE | 3835211003PD |
| Mintex | MDC2380 |
| Mintex | MDCB2380 |
| NK Autoparts | 3415103 |
| NK Autoparts | 3415119 |
| Optimal | BS9314 |
| Optimal | BS9314HC |
| PAGID Racing | 54418 |
| PAGID Racing | 54418PRO |
| PAGID Racing | 65155 |
| PAGID Racing | 65155HC |
| Pilenga | V803B1 |
| Remsa | 6149110 |
| SBS | 18153415103 |
| SBS | 18153415119 |
| Textar | 92141800 |
| Textar | 92141803 |
| Textar | 92141805 |
| Textar | 92141825 |
| Textar | 98200141801 |
| Topran | 501189 |
| TRW | DF6625S |
| VAICO | V2080061 |
| Zimmermann | 150343400 |
| Zimmermann | 150343420 |
| Zimmermann | 150343432 |
| Zimmermann | 150343452 |
| Zimmermann | 150343454 |
| Zimmermann | 150343455 |
| Zimmermann | 150343470 |
| Zimmermann | 150343472 |
| Zimmermann | 150343475 |
Fits Years: 2004 2005 2006 2007 2008 2009 2010
Fits Models: 535i, 545i, 550i, 645Ci, 650i
