| Attribute | Value |
|---|---|
| 120.00 | |
| ABS Tone Ring Included | No |
| Assy/Disassy By Qualified Personnel Required! | . |
| Balancing Type | Mill Balancing |
| Bearings Included | No |
| Bolt Hole Circle Ø [in] | 4.72 |
| Bolt Hole Circle Ø [mm] | 120 |
| Bolt Hole Quantity | 6 |
| Brake Disc Thickness [in] | 1.18 |
| Brake Disc Thickness [mm] | 30 |
| Brake Disc Type | Internally Vented |
| California Proposition 65 Required | No |
| Center Hole Diameter | 120.0 |
| Color | Silver |
| Colour | Silver |
| Construction | Full Cast |
| Directional Or Non Directional Brake Surface | Non-directional |
| Disc Finish | Coated |
| Discard Thickness | 28.40 |
| Grade Type | Standard Replacement |
| Hat Finish | Coated |
| Height [in] | 2.44 |
| Hole Arrangement / Number | 05/06 |
| Hole Arrangement/Number | 05/06 |
| Inside Diameter | 75.1 |
| Machining | High-carbon |
| Material | Gray Cast Iron |
| Minimum Thickness [mm] | 28,4, 28.4 |
| Mounting Bolt Hole Circle Diameter | 120.00 |
| Mounting Bolt Hole Quantity | 6 |
| Nominal Thickness | 30.00 |
| Number Of Bolts/screws | 1 |
| Outer Diameter [in] | 13.70 |
| Overall Height | 62.00 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Vented |
| Surface | Coated |
| Surface Type | Smooth |
| Technical Information Number | 54609pro_hc_na |
| Weight [kg] | 12,6, 12.6 |
| Wheel Bolt Bore Diameter [in] | 0.67 |
| Wheel Bolt Bore Diameter [mm] | 17 |
| Wheel Bolt Bore Ø [in] | 0.67 |
| Wheel Bolt Bore Ø [mm] | 17 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| 3.0si | SUV | 2007 - 2009 | L6 3.0L | AWD Automatic |
| 4.8i | SUV | 2007 - 2008 | V8 4.8L | AWD Automatic |
| 4.8i Premium | SUV | 2007 - 2009 | V8 4.8L | AWD Automatic |
| Base | SUV | 2014 - 2015 | L6 3.0L Turbo | AWD Automatic |
| Excellence | SUV | 2014 - 2016 | L6 3.0L Turbo | AWD Automatic |
| Excellence | SUV | 2014 - 2016 | V8 4.4L Turbo | AWD Automatic |
| M | SUV | 2012 | L6 3.0L Turbo | AWD Automatic |
| M | SUV | 2011 | L6 3.0L | AWD Automatic |
| M | SUV | 2010 - 2018 | V8 4.4L Turbo | AWD Automatic |
| M Edition Black Fire | SUV | 2018 | V8 4.4L Turbo | AWD Automatic |
| M Sport | SUV | 2015 - 2016 | V8 4.4L Turbo | AWD Automatic |
| M Sport | SUV | 2014 - 2016 | L6 3.0L Turbo | AWD Automatic |
| sDrive35i | SUV | 2014 - 2018 | L6 3.0L Turbo | RWD Automatic |
| xDrive30i | SUV | 2011 - 2013 | L6 3.0L Turbo | AWD Automatic |
| xDrive30i | SUV | 2011 - 2013 | V8 4.4L Turbo | AWD Automatic |
| xDrive30i | SUV | 2009 - 2011 | L6 3.0L | AWD Automatic |
| xDrive30i M Sport | SUV | 2009 - 2010 | L6 3.0L | AWD Automatic |
| xDrive35d | SUV | 2009 - 2018 | L6 3.0L DIESEL Turbo | AWD Automatic |
| xDrive35i | SUV | 2011 | L6 3.0L | AWD Automatic |
| xDrive35i | SUV | 2011 - 2018 | L6 3.0L Turbo | AWD Automatic |
| xDrive35i | SUV | 2011 - 2013 | V8 4.4L Turbo | AWD Automatic |
| xDrive35i Excellence | SUV | 2017 - 2018 | L6 3.0L Turbo | AWD Automatic |
| xDrive35i M Sport | SUV | 2017 - 2018 | L6 3.0L Turbo | AWD Automatic |
| xDrive40e | SUV | 2016 - 2018 | L4 2.0L PLUG-IN HYBRID EV-GAS (PHEV) Turbo | AWD Automatic |
| xDrive40e Excellence | SUV | 2016 - 2018 | L4 2.0L PLUG-IN HYBRID EV-GAS (PHEV) Turbo | AWD Automatic |
| xDrive48i | SUV | 2009 - 2010 | V8 4.8L | AWD Automatic |
| xDrive48i M Sport | SUV | 2009 - 2010 | V8 4.8L | AWD Automatic |
| xDrive50i | SUV | 2011 - 2018 | V8 4.4L Turbo | AWD Automatic |
| xDrive50i Excellence | SUV | 2017 - 2018 | V8 4.4L Turbo | AWD Automatic |
| xDrive50i M Sport | SUV | 2017 - 2018 | V8 4.4L Turbo | AWD Automatic |
| xDrive50i Security | SUV | 2018 | V8 4.4L Turbo | AWD Automatic |
| xDrive50i Security Plus | SUV | 2018 | V8 4.4L Turbo | AWD Automatic |
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| ActiveHybrid | SUV | 2010 | V8 4.4L FULL HYBRID EV-GAS (FHEV) Turbo | AWD Automatic |
| M | SUV | 2010 | V8 4.4L Turbo | AWD Automatic |
| xDrive35i | SUV | 2008 - 2010 | L6 3.0L Turbo | AWD Automatic |
| xDrive35iA | SUV | 2009 - 2010 | L6 3.0L Turbo | AWD Automatic |
| xDrive50i | SUV | 2008 - 2010 | V8 4.4L Turbo | AWD Automatic |
| xDrive50iA | SUV | 2009 - 2010 | V8 4.4L Turbo | AWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Akebono | BN0503 |
| Akebono | BN0503E |
| AMC | FO4196 |
| Ashuki | P330160 |
| ATE | 24013001991 |
| ATE | 430199 |
| Bendix | 521428 |
| Bendix | 562520BC |
| Bendix | BR2864 |
| Bendix | BR2864ULT |
| Blue Print | ADB114302 |
| BMW | 34 11 6 868 938 |
| BMW | 34 41 6 198 986 |
| BMW | 34 41 6 324 244 |
| BMW | 34 41 6 647 477 |
| BMW | 34116868938 |
| BMW | 6 771 986 |
| BMW | 6 793 244 |
| BMW | 6 868 938 |
| BMW | 6886477 |
| Borg & Beck | BBD5823S |
| Bosch | 0986479436 |
| Bosch | 0986AB5812 |
| Bosch | 0986T16812 |
| Bosch | F026A09408 |
| Brake Engineering | DI956592S |
| Brembo | 09992210 |
| Brembo | 09992211 |
| Brembo | 09992214 |
| Brembo | 0999221X |
| Cifam | 8001326C |
| Delphi | BG9063 |
| Delphi | BG9063C |
| Delphi | BG9063C18B1 |
| Dynamic Friction Company | 600-31142 |
| Dynamic Friction Company | 604-31142 |
| Dynamic Friction Company | 900-31142 |
| EBC Brakes | D1521 |
| EBC Brakes | GD1521 |
| EBC Brakes | USR1521 |
| Febi-Bilstein | 32261 |
| Ferodo | DDF1713 |
| Ferodo | DDF1713C |
| Ferodo | DDF1713C1 |
| Ferodo | DDF1713C1D |
| Ferodo | DDF1713DSL1D |
| Ferodo | DDF1713DSR1D |
| Ferodo | DDF1713X |
| FREMAX BRAKE ROTORS AND DRUMS | BD1986 |
| FTE | 9071023 |
| FTE | 9081038 |
| FTE | 9081327 |
| FTE | BS7245 |
| FTE | BS7245B |
| FTE | BS7245HB |
| Girling | 6048535 |
| Hella Pagid | 54609PROHCNA |
| Hella Pagid | 8DD355122902 |
| Japan Parts | DI0141 |
| Japan Parts | DI0141C |
| JP Group A/S | 1463106200 |
| Jurid | 562520JC |
| Jurid | 562520JC1 |
| LPR | B2040V |
| LPR | B2040VR |
| Magneti Marelli | 360406068600 |
| METELLI | 231326C |
| MEYLE | 3155210005PD |
| MEYLE | 3835210005PD |
| Mintex | MDC2328 |
| Mintex | MDC82328C |
| NK Autoparts | 201587 |
| NK Autoparts | 311587 |
| NK Autoparts | 341587 |
| Optimal | BS8350 |
| Optimal | BS8350C |
| Optimal | BS8350HC |
| PAGID Racing | 54609 |
| PAGID Racing | 54609HC |
| PAGID Racing | 54609PRO |
| Remsa | 6133510 |
| SBS | 1815201587 |
| SBS | 1815311587 |
| SBS | 1815341587 |
| Textar | 92160900 |
| Textar | 92160903 |
| Textar | 92160905 |
| Textar | 98200160901 |
| Topran | 502015 |
| Trucktec | 0834148 |
| TRW | DF4853S |
| VAICO | V2080077 |
| Valeo | 197178 |
| Valeo | 297178 |
| Zimmermann | 150344820 |
| Zimmermann | 150344852 |
| Zimmermann | 150344854 |
| Zimmermann | 150344855 |
| Zimmermann | 150344870 |
| Zimmermann | 150344872 |
| Zimmermann | 150344875 |
Fits Years: 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018
Fits Models: X5, X6
