Snapshot

The Hyundai Veloster headlight-also called a headlamp, front lamp, or light assembly-illuminates the road, helps others see your hatchback-coupe, and is required by law. First-generation cars (2012-2017) use replaceable halogen bulbs, while second-generation models (2019-2022) add projector housings and, on "N" trims, sealed LED units. The lights include useful features such as an automatic "escort" or "welcome" delay, built-in leveling, and daytime running lamps. Federal Motor Vehicle Safety Standard No. 108 (FMVSS 108) sets design rules for every replacement lamp in the U.S., and safety data show that clean, properly-aimed headlights can double night-time visibility. (ManualsLib, NHTSA, AAA Newsroom)

Fitment Years

• 2012-2017 (1st gen): Halogen reflector high beam (H7) and halogen low beam (H7 or H11B in projectors). (ManualsLib)
• 2019-2022 (2nd gen): Projector low beam (H7), reflector high beam (9005 HB3). (ManualsLib)
• Veloster N (2019-2022): Factory LED low beams with integrated high-beam reflector; no serviceable bulb. (Velostern)

Bulb & Light Types

• Halogen: Common, low-cost filament bulb used on most trims. Replace after roughly 500 hours or if glass darkens. (ManualsLib)
• LED modules (N-line): Cooler-running, longer-lasting diodes fixed inside the housing-replacement requires swapping the full assembly. (Velostern)
• Daytime Running Lights (DRL): Reduce daytime crash risk and use separate low-power filaments or LEDs. (ManualsLib)
• Fuse & Relay protection: Headlight fuses (10 A IG2, 50 A B+2/B+3) sit in the under-hood box on 2011-2017 cars; 2018-2022 cars move some lighting relays to an interior panel. (Fuse Box, Fuse Box)

Key Features

• Escort / Welcome function keeps lamps on up to 30 seconds so you can safely walk away at night. (ManualsLib)
• Beam-leveling switch lowers or raises the pattern based on cargo or passenger load. (ManualsLib)
• Automatic light sensor toggles the system when ambient light drops. (Veloster)

Common Problems

• Burned-out bulbs-symptom: one side dark; solution: replace bulb, inspect socket for heat damage. (Veloster)
• Condensation or fogging-light mist inside lens after rain is considered normal by Hyundai; heavy water pooling signals a leak that needs sealing or a moisture-absorber pack. (NHTSA, N-cars)
• Cloudy polycarbonate lenses lose up to 80 % of original brightness; plastic restoration or replacement restores light output. (AAA Newsroom)
• Mis-aimed beams cause glare or short sight distance; adjust with the 8 mm screw on top of each housing. (Veloster)

Maintenance Tips

1. Clean lenses with mild soap monthly; avoid abrasive cleaners that scratch the clear coat.
2. Inspect fuses if both beams fail; check the 10 A and 50 A links in the engine bay box first. (Fuse Box)
3. Handle halogen bulbs with gloves-skin oil shortens life. (ManualsLib)
4. Aim headlights on a flat surface 25 ft (7.6 m) from a wall; horizontal cut-off should fall just below headlight center height. (Veloster)

Basic Repair Steps

1. Open hood and remove the black plastic bulb cover (turn counter-clockwise). (ManualsLib)
2. Unplug the wiring connector and release the spring clip.
3. Swap the bulb, avoiding glass contact, then reverse steps.
   For LED assemblies, remove the front bumper fascia first to reach the three 10 mm mounting bolts holding each headlight. (Veloster Turbo)

Upgrades & Mods

• Higher-output halogen bulbs (55 W) fit the stock H7 or 9005 sockets and increase brightness about 20 %.
• After-market LED retrofit bulbs can reduce power draw, but must still meet FMVSS 108 photometric rules to stay street-legal. (NHTSA)
• Clear wrap or amber-delete vinyl personalizes style while protecting the lens surface. (Premium Auto Styling)

Safety & Legal

• The Insurance Institute for Highway Safety rates the base halogen projector on 2021 models as Poor, noting limited right-side reach; selecting the upgraded LED package improves the score to Acceptable. (IIHS-HLDI)
• FMVSS 108 bans glare-producing conversions and requires every replacement lamp or bulb to be DOT-certified. (NHTSA)
• Clouded lenses cut low-beam light to 20 % of new output, doubling crash risk after dark. (AAA Newsroom)

Troubleshooting

← scroll table horizontally →

Sources: fuse-box diagrams, Hyundai manuals, forum diagnostics. (Fuse Box, ManualsLib, Veloster)

Frequently Asked Questions

Q: What bulb size is in my 2015 Veloster low beam?
A: Most 2012-2017 cars use an H7 halogen for both high and low beams unless they have factory projectors, which switch the low beam to H11B. (ManualsLib)

Q: Does the 2020 Veloster N have replaceable bulbs?
A: No. The low beam is a sealed LED module. If it fails, swap the whole lamp. (Velostern)

Q: My headlamp has light mist after washing-do I need a new unit?
A: Light condensation is normal and should clear after driving with the lights on for 30 minutes. Only persistent water pooling calls for repair. (NHTSA)

Q: How do I aim the lights?
A: Insert a long Phillips or 8 mm driver into the vertical adjuster behind the housing; turn clockwise to lower, counter-clockwise to raise. (Veloster)

Q: Are LED retrofit bulbs legal?
A: They are legal only if they are certified to meet FMVSS 108 photometric and beam-pattern rules. (NHTSA)

Q: Why do my lenses look yellow?
A: Sunlight degrades the plastic clear coat; cleaning kits or full replacement restores brightness. (AAA Newsroom)

Q: Where is the headlight fuse on a 2013 Veloster?
A: It's fuse #15 (10 A) in the interior panel and a 50 A main fuse in the engine bay box. (Fuse Box)

Q: Can I fit HID bulbs in the stock reflector housing?
A: It's not recommended because the beam pattern can create glare and fail inspection. Choose projector-specific HID kits or LED conversions tested for your lamp. (NHTSA)

Q: What is the "escort" headlight feature?
A: When you remove the key and open the driver's door, the lights stay on up to 30 seconds to light your path home. (ManualsLib)

Q: My new bulb still doesn't work-what else should I check?
A: Inspect the connector for melted pins and verify ground wires are tight on the chassis near the lamp bracket. (Veloster)

Helpful Links

• Hyundai Veloster Owner's Manual - bulb removal
• FMVSS 108 regulations
• IIHS headlight ratings
• AAA research on cloudy headlights
• Fuse-box diagrams 2011-2017

Maintain bright, clear, and well-aimed headlights to keep your Veloster-and everyone around you-safe on the road at night.
