Highlights

The Kia Optima's tail light-also called the rear combination lamp, taillamp, brake-light assembly, stop lamp, or rear lamp-is a safety device that lets drivers behind you see the car at night, during braking, and while turning. U.S. rules under FMVSS No. 108 set color, brightness, and placement limits. From 2011-2020 most Optimas use LED boards for the running and brake functions on upper trims, while base models keep twin-filament 1157 or single-filament 1156 incandescent bulbs for turn and reverse lights (Car and Driver, Car and Driver). LEDs reach full brightness about a quarter-second faster than old bulbs, cutting reaction distance by roughly 15-30 ft at highway speed, according to NHTSA lab work (Crash Statistics, NHTSA). Kia issued Technical Service Bulletins (TSBs) to stop water leaks that fog early TF-generation lamps and to replace faulty stop-lamp switches on some 2008-2011 cars (NHTSA, NHTSA, NHTSA).

Model Years

2011-2015 (TF)

• First Optima with optional full-LED tail lamps on SX and Limited; lower trims use bulb/LED mixes (Car and Driver).
• TSB BOD172 (2017) addresses pad sealing to cure water intrusion under heavy rain (NHTSA).

2016-2020 (JF)

• Redesigned rear lights stretch wider for better side visibility and adopt brighter LED strips as standard on EX/SX, noted by Car and Driver's launch review (Car and Driver).
• Optical "zig-zag" full-width LED bar added on 2021-present K5 successor for signature look (Car and Driver).

How It Works

• Running lamp: low-intensity red glows whenever headlights are on.
• Brake/stop lamp: high-intensity red comes on with pedal; FMVSS demands ≥5 cd at 10° down and 10° left test points (GovInfo).
• Rear turn signal: amber (global) or red (U.S.) flashing filament or LED.
• Reverse light: clear lens, white bulb to illuminate 7.5 m behind car per FMVSS table XII (eCFR).
• Reflector: passive red plastic ensures the sedan is visible when parked.

LED vs. Bulb

• LEDs light in under 10 ms; incandescent takes ~250 ms, improving following drivers' reaction time by 0.25-0.35 s in tests (PubMed, NHTSA, NHTSA).
• LEDs last 30,000-50,000 hr and draw 70 % less current, easing alternator load and allowing smaller wire gauge (ScienceDirect).
• Downside: if a diode array fails, you replace the whole lamp, not a cheap bulb.

Common Issues

← scroll table horizontally →

DIY Replacement

1. Open trunk, pull fabric cover behind lamp.
2. Unplug 6-pin harness by squeezing lock tab.
3. Remove three 10 mm nuts; support lamp to avoid drops (NHTSA).
4. Wiggle lamp rearward; clear locating pins.
5. For bulb style: twist socket ¼-turn CCW, replace with 1157 (dual) or 1156 (single) bulb-wear gloves to avoid oil spots.
6. For LED module: transfer foam pad and reuse harness.
7. Refit lamp, torque to spec, test all functions before closing trim.

Tip: After market paint work, check the gasket sits flush; a hair-thick gap is enough to let water seep inside (NHTSA).

Upgrades

• Sequential LED boards add sweeping turn signals; ensure flash rate ≤120 cycles/min to stay legal.
• Add an external flasher module for "hyper-flash" prevention if you delete incandescent bulbs.
• For show cars, integrate a "startup animation" but verify FMVSS S6.1.5 forbids animation while braking or turning on public roads (eCFR).

Care Tips

• Wash lens with pH-neutral soap; harsh cleaners dull UV coating.
• Apply plastic polish twice a year to fight oxidation.
• Check lamp-to-body bolts every oil change; vibration loosens them.
• Keep trunk tidy-loose cargo can crack the inner tail lamp.

Frequently Asked Questions

Q: What bulb fits a 2015 LX tail light?
A: The outer turn and stop/running functions share a dual-filament 1157 bulb, while the reverse light uses a single-filament 1156. Always match the original wattage. (Car and Driver)

Q: Are Optima tail lights LED?
A: SX and higher trims from 2011 forward have LED running and brake sections; lower trims rely on bulbs, though all versions switched to LED by 2020. (Car and Driver)

Q: Why is condensation inside my lamp?
A: A factory gasket gap on 2011-2015 cars lets water in; Kia issued a pad-upgrade TSB to fix it. (NHTSA)

Q: Can I drive with a cracked lens?
A: It's legal trouble. FMVSS 108 requires red light and reflector visibility; a missing chunk can earn a ticket and reduce safety. (eCFR)

Q: Do LEDs last forever?
A: No. Heat cycles can kill diode chips, but they typically outlive the car's warranty-often 10+ years. (ScienceDirect)

Q: How much does a replacement lamp cost?
A: Prices vary by LED vs. bulb style; expect around $60 for bulb housings and $180-$350 for LED assemblies (parts only). Labor is under 30 minutes.

Q: Will changing the tail light void my warranty?
A: Using a quality aftermarket part that meets FMVSS specs will not void warranty under U.S. Magnuson-Moss laws.

Q: Do I need to disconnect the battery first?
A: It's recommended to avoid accidental shorts, especially on LED models with sensitive circuits.

Q: Where is the tail-light fuse?
A: Check the rear-seat side fuse-box; the label often reads "TAIL LP" or "RR LAMP".

Q: Can I install sequential signals legally?
A: Yes, if each flash stays between 60-120 per minute and the red or amber color stays unchanged.
