Before diving in, here are the big take-aways: Lincoln Town Car headlights (also called headlamps, front lamps, or light assemblies) changed very little from 1998-2011, mostly use 9006 low-beam and 9005 high-beam bulbs, must meet Federal Motor Vehicle Safety Standard 108, and are easy to swap with basic hand tools. Typical problems are dimming, moisture, and poor aim. Good upkeep restores factory-level night vision and helps the big sedan pass safety tests.

Key Facts

• The Town Car was built across three generations from 1981-2011; the final body style (1998-2011) is the one most people still maintain today. (Wikipedia)
• Ford offered halogen optics on all years and optional HID low-beams (bulb D1R) on some 2003-2011 Signature L and Cartier trims. (ManualsLib)
• Low-beam 9006 and high-beam 9005 bulbs sit in a combined reflector housing; the module is held by three 8 mm bolts that come out in minutes. (, YouTube)
• U.S. law requires every replacement lamp to self-certify compliance with FMVSS 108 for brightness, beam pattern, and marking. (NHTSA)

Fit & Years

← scroll table horizontally →

Bulb Specs

• Halogen set-up - 9006 (low) & 9005 (high) 12 V 55-65 W. (ManualsLib)
• Factory HID - Low beam uses D1R capsule; high beam stays 9005.
• Fog lamps - 9145 bulbs in the lower bumper.
• Always unplug the battery when swapping HID parts; the igniter runs at 25 kV.

Common Issues

• Condensation - Small droplets form after rain or a car-wash. Vent holes usually clear moisture once lights warm up; persistent fog points to a cracked seal. (Reddit, The Irish Sun)
• Dimming - Filament wear, hazed lenses, or corroded grounds cut light by >30 %. HID capsules also fade after ~2,000 h. (NHTSA)
• One side out - First check fuse #13 and the micro-relay in the engine-bay box before replacing the bulb. (YouTube, The Scottish Sun)

Install Steps

1. Open hood and remove the three 8 mm retainers.
2. Slide the headlight forward; disconnect the wiring plug.
3. Twist bulb counter-clockwise; swap in new unit (no bare fingers on glass).
4. Re-seat housing, tighten bolts finger-tight plus ¼-turn. (YouTube)

Aiming Guide

• Park 25 ft (7.6 m) from a flat wall, on level ground.
• Mark headlight center height on wall with tape.
• Turn vertical screw until the cut-off sits even with the tape; horizontal aim is fixed by the reflector and requires no adjustment on 1998-2011 models. (JustAnswer, Lincolns Online)

Maintenance Tips

• Wash lenses with mild soap, not glass cleaner - ammonia dries plastics.
• Polish yellowed lenses with a two-stage kit every 12-18 months.
• Replace bulbs in pairs so color and brightness match.
• Keep spare mini-fuses (15 A) in the glove box for road fixes. (The Scottish Sun)

Safety Rules

• FMVSS 108 limits glare to protect on-coming traffic; never aim beams above the trunk lid of a car parked ahead. (NHTSA)
• HID and LED retrofits must carry DOT markings to be road-legal.

Upgrade Paths

• LED drop-ins - Cut power draw by ~60 % and last up to 20,000 h, but choose units with a focused projector to maintain beam shape. (NHTSA)
• Clear-lens retrofit - Aftermarket glass lenses resist UV hazing longer than polycarbonate stock lenses.
• Relay harness - Supplies full battery voltage to halogens for a crisper beam.

Environmental Info

• Spent HID capsules contain trace mercury; recycle under EPA Universal Waste rules instead of tossing in regular trash. (US EPA, US EPA)

Frequently Asked Questions

Q: How long do Town Car halogen bulbs last?
A: Typical life is 450-700 hours, or about 2-3 years of mixed driving. (NHTSA)

Q: My lens is cloudy. Do I need a whole new headlight?
A: Usually not. Wet-sand and polish the outer surface; only replace the assembly if cracks or broken tabs appear. (Reddit)

Q: One low beam quit but the bulb looks okay. What now?
A: Check fuse #13 and the lighting relay; a $2 fuse often fixes a "dead" lamp. (YouTube, The Scottish Sun)

Q: Can I switch to LEDs without wiring mods?
A: Yes, plug-and-play LED conversions exist in 9006/9005 sizes, but confirm they are DOT-certified and fit under the dust cap. (NHTSA)

Q: Do I need to align new headlights?
A: Always re-check vertical aim after installation; a mis-aligned beam reduces visibility and can blind others. (JustAnswer)

Q: Why does water keep coming back inside the lens?
A: Look for a missing rear dust cover or a hairline crack around the perimeter gasket; seal or replace as needed. (Reddit)

Q: What's the color temperature of factory bulbs?
A: OEM halogens emit around 3,200 K (warm white). Optional HIDs run 4,100 K (neutral white). (NHTSA)

Q: Is horizontal adjustment possible?
A: No. The Town Car reflector locks side-to-side aim at the factory; you can only tweak vertical height. (Lincolns Online)

Q: How bright can I go and stay legal?
A: FMVSS 108 caps forward intensity at roughly 2,000 lumens per filament for halogen systems; follow that when choosing aftermarket bulbs. (NHTSA)

Q: Are headlight covers legal?
A: Tinted headlight shields that dim light more than a few percent violate FMVSS 108 and many state codes.
