| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Bearings Included | No |
| Center Hole Diameter | 3.09, 78.5 |
| Conventional Or Drum In Hat Type Rotor | Conventional |
| Directional Or Non Directional Brake Surface | Non-directional |
| Discard Thickness | 1.102, 28 |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 139.7, 5.5 |
| Mounting Bolt Hole Diameter | 0.625, 15.9 |
| Mounting Bolt Hole Quantity | 6 |
| Nominal Thickness | 1.181, 30 |
| Overall Height | 2.19, 55.65 |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 6 |
| UNSPSC Code | 25171715 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | SUV | 2012 | V8 5.3L | AWD Automatic |
| Base | SUV | 2012 | V8 5.3L FLEX | AWD Automatic |
| Base | SUV | 2011 | V8 5.3L | 4WD Automatic |
| Base | SUV | 2011 - 2012 | V8 5.3L FLEX | RWD Automatic |
| Base | SUV | 2011 | V8 5.3L FLEX | 4WD Automatic |
| Base | SUV | 2007 - 2009, 2011 - 2012 | V8 5.3L | RWD Automatic |
| Hybrid | SUV | 2010 - 2013 | V8 6.0L FULL HYBRID EV-FLEX (FHEV) | RWD/4WD Automatic |
| Hybrid | SUV | 2008 - 2009 | V8 6.0L FULL HYBRID EV-GAS (FHEV) | RWD/4WD Automatic |
| LS | SUV | 2007 - 2009 | V8 4.8L | RWD/4WD Automatic |
| LS | SUV | 2007 - 2009, 2016 - 2020 | V8 5.3L | 4WD Automatic |
| LS | SUV | 2007 - 2009, 2015 - 2020 | V8 5.3L | RWD Automatic |
| LS | SUV | 2007 - 2020 | V8 5.3L FLEX | RWD/4WD Automatic |
| LT | SUV | 2013 | V8 5.3L | AWD Automatic |
| LT | SUV | 2013 | V8 5.3L FLEX | AWD Automatic |
| LT | SUV | 2007 - 2009, 2014, 2016 - 2020 | V8 5.3L | 4WD Automatic |
| LT | SUV | 2007 - 2009, 2013 - 2020 | V8 5.3L | RWD Automatic |
| LT | SUV | 2007 - 2020 | V8 5.3L FLEX | RWD/4WD Automatic |
| LTZ | SUV | 2015 - 2016 | V8 5.3L | AWD Automatic |
| LTZ | SUV | 2009 | V8 6.2L FLEX | RWD/4WD Automatic |
| LTZ | SUV | 2008 | V8 6.2L | RWD/4WD Automatic |
| LTZ | SUV | 2007 - 2009, 2016 | V8 5.3L | RWD/4WD Automatic |
| LTZ | SUV | 2007 - 2016 | V8 5.3L FLEX | RWD/4WD Automatic |
| Midnight Edition | SUV | 2018 | V8 5.3L | AWD Automatic |
| Midnight Edition | SUV | 2018 | V8 5.3L FLEX | AWD Automatic |
| PPV | SUV | 2015 - 2020 | V8 5.3L FLEX | 4WD Automatic |
| PPV | SUV | 2007 - 2020 | V8 5.3L FLEX | RWD Automatic |
| Police | SUV | 2014, 2017 - 2020 | V8 5.3L FLEX | RWD Automatic |
| Premier | SUV | 2018 - 2019 | V8 5.3L | AWD Automatic |
| Premier | SUV | 2018 - 2020 | V8 6.2L | RWD/4WD Automatic |
| Premier | SUV | 2018 - 2020 | V8 6.2L FLEX | RWD/4WD Automatic |
| Premier | SUV | 2017 - 2020 | V8 5.3L | RWD/4WD Automatic |
| Premier | SUV | 2017 - 2020 | V8 5.3L FLEX | RWD/4WD Automatic |
| Premier | SUV | 2017 - 2019 | V8 5.3L FLEX | AWD Automatic |
| SSV | SUV | 2012 - 2020 | V8 5.3L FLEX | 4WD Automatic |
| Z71 | SUV | 2017 | V8 5.3L FLEX | AWD Automatic |
| Z71 | SUV | 2016 | V8 5.3L | AWD Automatic |
| Z71 | SUV | 2010 | V8 5.3L FLEX | 4WD Automatic |
| Z71 | SUV | 2008 - 2009 | V8 5.3L | RWD Automatic |
We offer fast, reliable shipping on all orders:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
We want you to be 100% satisfied with your purchase. That's why we offer:
| Brand | Part Number |
|---|---|
| ACDelco | 177-0918 |
| Advance Auto Parts | G12518SD |
| Advance Auto Parts | YH145582 |
| Advance Auto Parts | YH145582C |
| Advance Auto Parts | YH145582P |
| Autopartsource | 593715 |
| Autoxtra | 80580279 |
| Autoxtra | AX55097 |
| AutoZone | 55097DG |
| AutoZone | 55097DL |
| Bendix | 145582 |
| BrakeBest | 521581RGS |
| BrakeBest | 580279RGS |
| BrakeBest | 81-126358 |
| Brembo | 09.A406.10 |
| Brembo | 27416 |
| Casting Numbers | 18048387 |
| Casting Numbers | 326223 |
| Centric Parts | 120.66057 |
| Centric Parts | 120.66057CRY |
| Centric Parts | 121.66057 |
| Centric Parts | 125.66057 |
| Centric Parts | 125.66057CRY |
| Centric Parts | 126.66057CSL |
| Centric Parts | 126.66057CSR |
| Centric Parts | 126.66057SL |
| Centric Parts | 126.66057SR |
| Centric Parts | 127.66057CL |
| Centric Parts | 127.66057CR |
| Centric Parts | 127.66057L |
| Centric Parts | 127.66057R |
| Centric Parts | 128.66057CL |
| Centric Parts | 128.66057CR |
| Centric Parts | 128.66057L |
| Centric Parts | 128.66057R |
| Centric Parts | 227.66057L |
| Centric Parts | 227.66057R |
| Centric Parts | 320.66057 |
| Dura Corp | BR55097 |
| Dura Corp | BR5509702 |
| Dynamic Friction Company | 604-48050 |
| General Motors | 22818355 |
| General Motors | 22950036 |
| General Motors | 23144340 |
| General Motors | 25819670 |
| General Motors | 88963556 |
| Mighty Distributing System | 55097 |
| Performance Friction | 326.056.01 |
| PowerStop | AR82132EVC |
| PowerStop | AR8654EVC |
| Promax | 14-55097 |
| Promax | 20-55097 |
| Qualis | 41252 |
| Quality Brand | Q4214 |
| Ultra Brake | 55402 |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X51681 |
| WABCO - Archived | PS126358 |
| Wagner Brake | BD126358 |
| Wagner Brake | BD126358E |
| Wagner Brake | BD180409 |
| Wagner Brake | BD180409E |
| Winhere | 6620538 |
Fits Years: 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019 2020
Fits Models: Tahoe
