This part comes with our industry-leading lifetime warranty. Shop with confidence!
Let Wrenchy help you confirm if this is the right part.
Detailed specifications and attributes for this part:
| Attribute | Value |
|---|---|
| Bearing Cap Diameter (1) | 1.188 |
| Bearing Cap Diameter (2) | 1.188 |
| Bearing Cap Diameter A (mm) | 30.175 |
| Bearing Cap Diameter B (mm) | 30.175 |
| Bearing Cap Finish | Ground |
| Bearing Cap Type | Round |
| Bearing Cap Type A | Osr |
| Bearing Cap Type B | Osr |
| Coating Type | None |
| Grease Fitting Location | One Straight Lube Fitting In Cross |
| Grease Type | N.l.g.i. Grade 2 |
| Grease Zerk Included | Y |
| Greaseable | Y |
| Length A (In) | 3.625 |
| Length A (mm) | 92.1 |
| Length B (In) | 3.625 |
| Length B (mm) | 92.1 |
| Material | Steel |
| Model Number | Spicer 1350 (spl30) |
| Mounting Hardware Included | N |
| OEM Mfg | Spicer |
| OEM Series | 1350 |
| Pre Greased | N |
| Prop 65 | Yes |
| SR(1)Brng Cap To Brng Cap(OSR) | 3.625 |
| SR(2)Brng Cap To Brng Cap(OSR) | 3.625 |
| Seal Color/Finish | Blue |
| Seal Material | Rubber |
| Snap Ring Included | Y |
| Snap Ring Type | External |
| Type | Osr Style |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| A | SUV | 2006 - 2007 | L6 4.2L | RWD Automatic |
| B | SUV | 2006 - 2007 | L6 4.2L | RWD Automatic |
| B | SUV | 2006 | L6 4.2L | 4WD Automatic |
| Base | SUV | 2008 | L6 4.2L | 4WD Automatic |
| Base | SUV | 2008 | V8 5.3L | RWD/4WD Automatic |
| Base | SUV | 2006 - 2008 | L6 4.2L | RWD Automatic |
| LS | SUV | 2006 - 2007 | L6 4.2L | RWD/4WD Automatic |
| LS | SUV | 2006 - 2007 | V8 5.3L | RWD/4WD Automatic |
| LT | SUV | 2006 - 2009 | L6 4.2L | RWD/4WD Automatic |
| LT | SUV | 2006 - 2008 | V8 5.3L | RWD/4WD Automatic |
| SS | SUV | 2006 - 2009 | V8 6.0L | AWD/RWD Automatic |
⚠️ Important: Please verify your vehicle's year, make, model, and specifications before ordering. If you're unsure about fitment, contact our customer service team for assistance.
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| ACDelco | 45U0103 |
| ACDelco | 45U0109 |
| ACDelco | 45U0123 |
| Allison Transmission | 00002422475 |
| Allison Transmission | 02330781 |
| AM General | 5714519 |
| American Lafrance | SP 5 178X |
| Broderson | 33370001 |
| Cameco | 0270006410 |
| Cameco | 02706410 |
| Caterpillar | 5V-7199 |
| Chrysler | 4723672 |
| Chrysler | 4797 307AB |
| Chrysler | 4797307 |
| Chrysler | 4797307AB |
| Chrysler | 6800 4848AB |
| Chrysler | 6803 6714AA |
| Chrysler | 68036714AA |
| Chrysler | 6804 8402AA |
| Chrysler | 6804 8402AB |
| Chrysler | 68048402AA |
| Chrysler | 68048402AB |
| Chrysler | 6806 7351AA |
| Chrysler | 68067351AA |
| Clarke | 6635419 |
| Clarke | 865335 |
| Cusco Fab | DR014074 |
| Daimler Truck North America | SP 5 178XHP |
| Dana Commercial Vehicle Service Parts | 2104-5178X |
| Dana Commercial Vehicle Service Parts | 5-178X25 |
| Dana Commercial Vehicle Service Parts | 5-584X |
| Dana Commercial Vehicle Service Parts | DT178 |
| Dana Commercial Vehicle Service Parts | SP5178X |
| Eagle | 01-0729-504 |
| Elgin | 7075410 |
| General Motors | 12471503 |
| General Motors | 12472409 |
| General Motors | 12476230 |
| General Motors | 12476231 |
| General Motors | 12522048 |
| General Motors | 23471515 |
| General Motors | 26049843 |
| General Motors | 374246 |
| General Motors | 7834387 |
| General Motors | 88964507 |
| General Motors | 88982758 |
| General Motors | 89059111 |
| GRADALL | 83743012 |
| Heyco | 837228 |
| Hyster | 27418A |
| INFINITI | 37126-7S025 |
| INFINITI | 37126-7S026 |
| INFINITI | 37126-7S225 |
| INFINITI | 371267S025 |
| INFINITI | 371267S026 |
| INFINITI | 371267S225 |
| Ingersoll Rand | 82149675 |
| Ingersoll Rand | 945413 |
| International Harvester IHC | 127573R91 |
| International Harvester IHC | 5178X |
| International Harvester IHC | D5174X |
| International Harvester IHC | D5178X |
| International Harvester IHC | E5178X |
| International Harvester IHC | SB5178X |
| International Harvester IHC | SD5178X |
| International Harvester IHC | ZJU5178X |
| Isuzu | 89 05 9111 |
| Jlg | 7011120 |
| John Deere | 840769100 |
| John Deere | AT76183 |
| McNeilus | 49198AX |
| Meritor | CP178X |
| Midwest | 5-178XR |
| Miller | 816718 |
| Motor Coach Industries | 06-06-1132 |
| Navistar | 5178X25 |
| Navistar | 5584X |
| Navistar | DS5178X |
| Navistar | E5480X |
| Navistar | SB5178X25 |
| New Holland Construction | 65484 |
| New Holland Construction | R2713 |
| New Holland Construction | V107034 |
| Paccar Parts | 27045 |
| Paccar Parts | 5-178X |
| Peterbilt | 10KP846 |
| Peterbilt | 3519122 |
| Peterbilt | 49198-AX |
| Precision | 231 |
| Precision | 232 |
| Precision | 331 |
| Precision | 331BL |
| Prevost | 194585 |
| Rockwell International | CP 178X |
| Sandvik | 293C5A9 |
| Sandvik | 36006273 |
| Sandvik | 3606273 |
| Sandvik | 5 178X |
| SKF | 2-0052 |
| SKF | 2-0053 |
| SKF | 2-0053G |
| SKF | 2-0799 |
| SKF | UJ231 |
| SKF | UJ232 |
| SKF | UJ331 |
| SKF | UJ331BL |
| Skyjacker | 128791 |
| SVL | 15-178X |
| Terex | 12333-70001 |
| Toyota | 04371-04080 |
| Toyota | 04371-0C080 |
| Toyota | 04371-0C081 |
| Toyota | 04371-0C082 |
| Toyota | 04371-0C090 |
| Toyota | 04371-0C093 |
| Toyota | 04371-0C094 |
| Toyota | 0437104080 |
| Toyota | 043710C080 |
| Toyota | 043710C081 |
| Toyota | 043710C082 |
| Toyota | 043710C090 |
| Toyota | 043710C093 |
| Toyota | 043710C094 |
| Volvo | 843150A |
| Volvo | SHP5178X |
| Volvo | SP 5178X |
Fits Years: 2006 2007 2008 2009
Fits Models: Trailblazer
