Voice or type your vehicle details and Wrenchy will confirm fitment in seconds.
| Attribute | Value |
|---|---|
| Air Vent (Bleeder Valve) | No, Non |
| Bolt Hole Center To Bolt Hole Center | 137.1, 97.5 |
| Bolts Included | No, Non |
| Color | Natural |
| Contenidos Del Paquete | 1 Caja Del Termostato |
| Flange Length | 96.35 |
| Flange Thickness | 4.75 |
| Flange Width | 67.64 |
| Gasket Or Seal Included | Oui, Sí, Yes |
| Gasket Type | O-ring, Sello Tipo O |
| Grade Type | Regular |
| Housing Color | Natural |
| Housing Neck Angle (°) | 120 Deg |
| Inlet Port Diameter | 38.2 |
| Inside Diameter | 29 |
| Junta Tórica Incluida | Sí |
| Material | Aluminio, Goma, Aluminum, Rubber |
| Mounting Hardware Included | No, Non |
| Mounting Hole Diameter | 10.6 |
| Mounting Hole Quantity | 5 |
| O Rings Included | Oui, Yes |
| Outlet Port Diameter | 20.8 |
| Salida De Aire (válvula De Purga) | No |
| Temperatura De Apertura Del Termostato | 188 Grados F |
| Thermostat Included | No, Non |
| Thermostat Opening Temperature | 188 Deg. F |
| Ángulo De Cuello De La Caja (°) | 120grados |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Cab & Chassis | 2015 - 2016 | L4 2.2L DIESEL Turbo | FWD/RWD Automatic & Manual |
| Base | Cab & Chassis | 2015 - 2016, 2018 - 2020 | L4 2.2L DIESEL Turbo | RWD Manual |
| Base | Cab & Chassis | 2015 - 2016 | V6 3.7L | FWD/RWD Automatic & Manual |
| Base | Standard Cargo Van | 2015 - 2016 | L4 2.2L DIESEL Turbo | FWD/RWD Automatic & Manual |
| Base | Standard Cargo Van | 2015 - 2016 | V6 3.7L | FWD/RWD Automatic & Manual |
| Base | Standard Passenger Van | 2015 - 2016 | L4 2.2L DIESEL Turbo | FWD/RWD Automatic & Manual |
| Base | Standard Passenger Van | 2015 - 2016 | V6 3.7L | FWD/RWD Automatic & Manual |
| Cargo | Extended Cargo Van | 2019 | L4 2.2L DIESEL Turbo | RWD Manual |
| Cargo | Extended Cargo Van | 2019 | V6 3.7L | RWD Manual |
| Cargo | Extended Cargo Van | 2018 - 2019 | L4 2.2L DIESEL Turbo | RWD Automatic |
| Cargo | Extended Cargo Van | 2018 - 2019 | V6 3.7L | RWD Automatic |
| Cargo | Standard Cargo Van | 2019 | L4 2.2L DIESEL Turbo | RWD Manual |
| Cargo | Standard Cargo Van | 2019 | V6 3.7L | RWD Manual |
| Cargo | Standard Cargo Van | 2018 - 2019 | L4 2.2L DIESEL Turbo | RWD Automatic |
| Cargo | Standard Cargo Van | 2018 - 2019 | V6 3.7L | RWD Automatic |
| Cargo | Standard Cargo Van | 2017 | L4 2.2L DIESEL Turbo | RWD Automatic |
| Cargo | Standard Cargo Van | 2017 | V6 3.7L | RWD Automatic |
| Jumbo | Standard Cargo Van | 2022 | L4 2.0L DIESEL Turbo | RWD Manual |
| Jumbo | Standard Cargo Van | 2020 | L4 2.2L DIESEL Turbo | RWD Manual |
| Jumbo 470E | Standard Cargo Van | 2021 | L4 2.0L DIESEL Turbo | RWD Manual |
| Larga | Cab & Chassis | 2022 | L4 2.0L DIESEL Turbo | RWD Manual |
| Larga 500L | Cab & Chassis | 2021 | L4 2.0L DIESEL Turbo | RWD Manual |
| Mediana | Cab & Chassis | 2022 | L4 2.0L DIESEL Turbo | RWD Automatic & Manual |
| Mediana | Cab & Chassis | 2022 | V6 3.5L | RWD Automatic & Manual |
| Mediana | Standard Cargo Van | 2022 | L4 2.0L DIESEL Turbo | RWD Automatic & Manual |
| Mediana | Standard Cargo Van | 2022 | V6 3.5L | RWD Manual |
| Mediana | Standard Cargo Van | 2020 - 2022 | V6 3.5L | RWD Automatic |
| Mediana 350M | Cab & Chassis | 2021 | L4 2.0L DIESEL Turbo | RWD Manual |
| Pasajeros | Extended Passenger Van | 2020 - 2022 | V6 3.5L | RWD Automatic |
| Pasajeros | Extended Passenger Van | 2020 | V6 3.5L | RWD Manual |
| Pasajeros | Extended Passenger Van | 2019 - 2020 | L4 2.2L DIESEL Turbo | RWD Manual |
| Pasajeros | Extended Passenger Van | 2019 | V6 3.7L | RWD Manual |
| Pasajeros | Extended Passenger Van | 2017 - 2020 | L4 2.2L DIESEL Turbo | RWD Automatic |
| Pasajeros | Extended Passenger Van | 2017 - 2019 | V6 3.7L | RWD Automatic |
| Pasajeros | Standard Passenger Van | 2020 | L4 2.2L DIESEL Turbo | RWD Automatic & Manual |
| Pasajeros | Standard Passenger Van | 2020 | V6 3.5L | RWD Automatic & Manual |
| Pasajeros 410L | Standard Passenger Van | 2021 - 2022 | L4 2.0L DIESEL Turbo | RWD Manual |
| Pasajeros 460E | Extended Passenger Van | 2021 - 2022 | L4 2.0L DIESEL Turbo | RWD Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Motorad | TA6013 |
Fits Years: 2015 2016 2017 2018 2019 2020 2021 2022
Fits Models: Transit
