Voice or type your vehicle details and Wrenchy will confirm fitment in seconds.
| Attribute | Value |
|---|---|
| Center Electrode Core Material | Copper |
| Center Electrode Design | Fine Wire |
| Center Electrode Insulator Tip Projection | 0.16, 4.0 |
| Center Electrode Projection | Mid Projection |
| Center Electrode Tip Material | Ruthenium |
| Electrical Terminal Type | Non-removable Nut |
| Grade Type | Performance |
| Ground Configuration | J-gap |
| Ground Electrode Core Material | Copper |
| Ground Electrode Quantity | 1 |
| Ground Electrode Tip Design | Projected Square Platinum Electrode (pspe) - High Ignitability |
| Ground Electrode Tip Material | Platinum |
| Hex Size | 5/8" (16mm) |
| Insulator Height | 1.99, 50.5 |
| Insulator Material | Ceramic |
| Manufacturer Heat Range | 5 |
| Material Grade | Ruthenium |
| Part Number | Fr5bhx |
| Pre Gap Size | .044, 1.1 |
| Reach | 0.750, 19.0 |
| Resistance | 5000.0 |
| Resistor Type | Yes |
| Seat Type | Flat |
| Service Number | Fr5bhx |
| Short Style Spark Plug | No |
| Skirt | No |
| Skirt Length | 0.0 |
| Stock Number | 96457 |
| Thread Diameter | 0.551, 14.0 |
| Washer Included | Yes |
| Washer Type | Crush |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Sedan | 1999 - 2004 | L4 2.4L | FWD Automatic & Manual |
| GL | Sedan | 2003 - 2005 | L4 2.4L | FWD Automatic & Manual |
| GL | Sedan | 2003 - 2005 | V6 2.7L | FWD Automatic & Manual |
| GLS | Sedan | 2002 - 2005 | V6 2.7L | FWD Automatic |
| GLS | Sedan | 2002 - 2003 | V6 2.7L | FWD Manual |
| GLS | Sedan | 1999 - 2001 | V6 2.5L | FWD Automatic & Manual |
| GLX | Sedan | 2005 | V6 2.7L | FWD Automatic |
| LX | Sedan | 2002 - 2005 | V6 2.7L | FWD Automatic |
| LX | Sedan | 2002 - 2003 | V6 2.7L | FWD Manual |
| VE | Sedan | 2005 | L4 2.4L | FWD Automatic & Manual |
| VE | Sedan | 2005 | V6 2.7L | FWD Automatic & Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Chrysler | 5071714AA |
| Chrysler | 5083433AA |
| Chrysler | 5149060AB |
| Chrysler | 68304168AA |
| Chrysler | SP00ZFR5AP |
| General Motors | 21024775 |
| General Motors | 21025103 |
| Hyundai | 18814-11051 |
| Hyundai | 18817-11051 |
| Hyundai | 27410 37100 |
| Hyundai | 27410-23700 |
| Isuzu | 8920633030 |
| Isuzu | 8971259690 |
| Isuzu | 8971702680 |
| Jaguar | AJ84575 |
| Jaguar | C2A1535 |
| Land Rover | 4550157 |
| Land Rover | LR00525 |
| Mazda | BP01-18-110 |
| Mazda | BP8K-18-110 |
| Mazda | F287-18-110 |
| Mazda | KJ13-18-110 |
| Mazda | KJ14-18-110 |
| Mercedes-Benz | A0031593103 |
| Mercedes-Benz | A0031594203 |
| Mercedes-Benz | A0031595403 |
| Mercedes-Benz | A0031596603 |
| Mercedes-Benz | A0031596703 |
| Mercedes-Benz | A0031596803 |
| Mercedes-Benz | A0031597103 |
| Mercedes-Benz | A0031597503 |
| Mercedes-Benz | A0031598603 |
| Mercedes-Benz | A0031599403 |
| Mercedes-Benz | A0041590903 |
| Mercedes-Benz | A0041591903 |
| Mercedes-Benz | A0041595003 |
| Mitsubishi | MD339798 |
| Mitsubishi | MD350292 |
| Mitsubishi | MD361067 |
| Mitsubishi | MD372553 |
| Mitsubishi | MS851357 |
| Mitsubishi | MS851571 |
| Mitsubishi | MS851727 |
| Subaru | 22401-AA570 |
| Subaru | 22401-AA650 |
| Subaru | 22401-AA65A |
| Toyota | 90080-91145 |
| Toyota | 90919-01176 |
| Toyota | 90919-01192 |
| Toyota | 90919-01193 |
| Toyota | 90919-01196 |
| Toyota | 90919-01197 |
| Volkswagen | 101000035AB |
| Volkswagen | 101000035AH |
Fits Years: 1999 2000 2001 2002 2003 2004 2005
Fits Models: Sonata
Keep your Sonata's engine running smoothly with the correct spark plugs and avoid common performance issues.
