| Attribute | Value |
|---|---|
| 4, Yes | |
| Attachment Method | Bolts |
| Bracket Included | No |
| Cap Included | Yes |
| Color | Black |
| Connector Gender | Male |
| Connector Shape | Na |
| Gasket Or Seal Included | No |
| Hose Size (In) | Na |
| Hose Size (mm) | Na |
| Inlet Diameter | Na |
| Inlet Diameter (In) | Na |
| Inside Diameter 1 (In) | .905 |
| Inside Diameter 1 (mm) | 23 |
| Inside Diameter 2 (In) | .764 |
| Inside Diameter 2 (mm) | 19.4 |
| Inside Diameter 3 (In) | Na |
| Inside Diameter 3 (mm) | Na |
| Inside Diameter 4 (In) | Na |
| Inside Diameter 4 (mm) | Na |
| Material | Pa6 |
| Nipple Orientation | Angled |
| OE Reference Number | 06f 129 101p |
| Outlet Diameter (In) | Na |
| Outlet Port Diameter | 22.85 |
| Port 1 Outside Diameter | 27 |
| Port 2 Outside Diameter | 22.85 |
| Port 3 Outside Diameter | 27 |
| Port Quantity | 4 |
| Terminal Gender | Na |
| Terminal Type | Na |
| Type | Diaphragm |
| Usage | Na |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| 2.0T | Convertible | 2007 - 2008 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| 2.0T | Convertible | 2007 | L4 2.0L Turbo | FWD Manual |
| 3.2 | Convertible | 2007 | V6 3.2L | FWD Automatic Dual Clutch |
| Base | Convertible | 2007 | L4 2.0L Turbo | FWD Manual |
| Comfortline | Convertible | 2009 | L4 2.0L Turbo | FWD Manual & Automatic Dual Clutch |
| Komfort | Convertible | 2008 - 2009 | L4 2.0L Turbo | FWD Manual & Automatic Dual Clutch |
| Lux | Convertible | 2008 - 2009 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| Trendline | Convertible | 2009 | L4 2.0L Turbo | FWD Automatic Dual Clutch |
| Turbo | Convertible | 2008 | L4 2.0L Turbo | FWD Manual & Automatic Dual Clutch |
| VR6 | Convertible | 2008 | V6 3.2L | FWD Automatic Dual Clutch |
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Hatchback | 2007 - 2008 | L4 2.0L Turbo | FWD Manual & Automatic Dual Clutch |
| Base | Hatchback | 2006 - 2008 | L4 2.0L Turbo | FWD Manual & Automatic Dual Clutch |
| Fahrenheit | Hatchback | 2007 | L4 2.0L Turbo | FWD Manual & Automatic Dual Clutch |
| Fahrenheit | Hatchback | 2007 | L4 2.0L Turbo | FWD Manual & Automatic Dual Clutch |
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| 2.0T | Sedan | 2006 | L4 2.0L Turbo | FWD Manual & Automatic Dual Clutch |
| 2.5 | Sedan | 2006 | L5 2.5L | FWD Automatic & Manual |
| 475 Aniversario | Sedan | 2006 | L4 2.0L | FWD Manual |
| Europa | Sedan | 2006 | L4 2.0L | FWD Manual |
| GL TDI | Sedan | 2006 | L4 1.9L DIESEL Turbo | FWD Automatic & Manual |
| GL TDI | Wagon | 2006 | L4 1.9L DIESEL Turbo | FWD Automatic & Manual |
| GLI | Sedan | 2006 | L4 2.0L Turbo | FWD Manual & Automatic Dual Clutch |
| GLS TDI | Sedan | 2006 | L4 1.9L DIESEL Turbo | FWD Automatic & Manual |
| GLS TDI | Wagon | 2006 | L4 1.9L DIESEL Turbo | FWD Automatic & Manual |
| Soccer 1 | Sedan | 2006 | L4 2.0L | FWD Manual |
| Soccer 2 | Sedan | 2006 | L4 2.0L | FWD Manual |
| TDI | Sedan | 2006 | L4 1.9L DIESEL Turbo | FWD Manual & Automatic Dual Clutch |
| TDI | Wagon | 2006 | L4 1.9L DIESEL Turbo | FWD Manual |
| Trendline | Sedan | 2006 | L4 2.0L | FWD Manual |
| Value Edition | Sedan | 2006 | L5 2.5L | FWD Automatic & Manual |
| Winter 1 | Sedan | 2006 | L4 2.0L | FWD Manual |
| Winter 2 | Sedan | 2006 | L4 2.0L | FWD Manual |
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| 2.0T | Sedan | 2008 | L4 2.0L Turbo | FWD Automatic & Manual |
| 2.0T | Wagon | 2008 | L4 2.0L Turbo | FWD Automatic & Manual |
| 3.6 | Sedan | 2008 | V6 3.6L | AWD/FWD Automatic |
| 3.6 | Wagon | 2008 | V6 3.6L | AWD/FWD Automatic |
| Base | Sedan | 2008 | L4 2.0L Turbo | FWD Automatic & Manual |
| Base | Wagon | 2008 | L4 2.0L Turbo | FWD Automatic & Manual |
| Komfort | Sedan | 2008 | L4 2.0L Turbo | FWD Automatic |
| Komfort | Wagon | 2008 | L4 2.0L Turbo | FWD Automatic |
| Lux | Sedan | 2008 | L4 2.0L Turbo | FWD Automatic |
| Lux | Wagon | 2008 | L4 2.0L Turbo | FWD Automatic |
| Turbo | Sedan | 2008 | L4 2.0L Turbo | FWD Automatic & Manual |
| Turbo | Wagon | 2008 | L4 2.0L Turbo | FWD Automatic & Manual |
| VR6 | Sedan | 2008 | V6 3.6L | AWD/FWD Automatic |
| VR6 | Wagon | 2008 | V6 3.6L | AWD/FWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Dorman | 264-728 |
| Febi-Bilstein | 47726 |
| Gates | EMH906 |
| HOLSTEIN | 2PCV0111 |
| IMC | 147 54040 740 |
| TechSmart | N16001 |
| TechSmart | V607 |
| URO Parts | URO-010796 |
| VAICO | V10-6458 |
| VAICO | V10-9751 |
| Volkswagen | 06F 129 101E |
| Volkswagen | 06F 129 101G |
| Volkswagen | 06F 129 101P |
| Volkswagen | 06F129101P |
Fits Years: 2006 2007 2008 2009
Fits Models: Eos, GTI, Jetta, Passat
