| Attribute | Value |
|---|---|
| Center Electrode Core Material | Copper |
| Center Electrode Design | Fine Wire |
| Center Electrode Insulator Tip Projection | 0.16, 4.0 |
| Center Electrode Projection | Mid Projection |
| Center Electrode Tip Material | Iridium |
| Electrical Terminal Type | Non-removable Nut |
| Grade Type | Performance |
| Ground Configuration | J-gap |
| Ground Electrode Core Material | Nickel |
| Ground Electrode Quantity | 1 |
| Ground Electrode Tip Design | Taper Cut |
| Ground Electrode Tip Material | Nickel |
| Hex Size | 13/16" |
| Insulator Height | 2.31, 58.6 |
| Insulator Material | Ceramic |
| Manufacturer Heat Range | 5 |
| Material Grade | Iridium |
| Part Number | Wr5ix |
| Pre Gap Size | .040, 1.0 |
| Reach | 0.429, 10.9 |
| Resistance | 5000.0 |
| Resistor Type | Yes |
| Seat Type | Tapered |
| Service Number | Wr5ix |
| Short Style Spark Plug | No |
| Skirt | No |
| Skirt Length | 0.0 |
| Stock Number | 7510 |
| Thread Diameter | 0.701, 18.0 |
| Washer Included | No |
This part fits the following vehicles:
This is a universal part that fits 4,067 vehicle configurations across 3 makes.
