Buy Subaru Outback Side View Mirrors

Quick Look

A side mirror (also called a wing mirror, door mirror, or outside rear-view mirror) on a Subaru Outback is more than a piece of glass-it is an electronic safety device that can include heating, power-folding, memory, auto-dimming, turn-signal repeaters, and radar indicators for Blind-Spot Detection. These smart mirrors must meet federal visibility rules, work with Subaru's EyeSight driver-assist tech, and-because of built-in sensors-can cost over a thousand dollars to replace if damaged.

Part Basics

• Location & Purpose - Bolted to each front door, the mirror lets you see cars, bikes, and curbs that the cabin mirror misses.
• Core Components - Housing, painted cap, pivot, glass, electric motor, wiring harness, and sometimes a radar module or puddle-light LED.
• Common Synonyms - Side-view mirror, wing mirror, door mirror, exterior mirror, power mirror.

Features & Tech

• Blind-Spot Detection light flashes on the inner edge when radar senses a car beside you.
• Lane Change & Rear Cross-Traffic alerts are integrated with EyeSight driver-assist.
• Heated glass clears ice whenever you press the rear-window defogger switch.
• Power-folding mirrors (optional) help the Outback fit in tight garages.
• Memory tilt-down aims the passenger mirror toward the curb when you reverse, then returns to its saved spot.
• Auto-dimming with approach lighting reduces night glare and lights the ground as you walk up.

Safety & Regulations

• U.S. rule FMVSS 111 sets minimum mirror size and field-of-view so drivers can see a 200-ft trailing car.
• 49 CFR 393.80 requires two secure outside mirrors on larger vehicles, but most design standards carry over to passenger cars.
• A recent class-action suit claims some 2024 Subaru mirrors shake at highway speed, blurring the view. (Top Class Actions)

Fitment Guide

← scroll table horizontally →

Tip: Legacy models that share the same chassis often use the same mirror mounting pattern, but wiring pins can differ-always match the part to your exact VIN.

Installation Tips

1. Unplug the battery to avoid air-bag or memory seat codes.
2. Pry off the interior sail trim and remove three 10 mm bolts.
3. Support the mirror; press the wire clip; slide the harness out.
4. Install new assembly, torque bolts snug, reconnect harness.
5. Run function checks (fold, heat, indicators, radar error codes).
   A DIY swap on 2010-14 models takes about 15 minutes with common tools, as shown in this step-by-step video guide.

Maintenance & Care

• Keep the glass clean with ammonia-free cleaner.
• Check that the rubber boot and wire sheath are intact each oil change to prevent corrosion.
• If the mirror vibrates, test for a broken mount and update the dealer on any recall bulletins. (Torque News)

Troubleshooting

← scroll table horizontally →

Upgrade Options

• Swap in auto-dimming housings to cut glare at night.
• Add puddle-light LEDs for safer entry in dark parking lots.
• Install convex glass on the passenger side for a wider view; ensure it meets local rules.

Cost Factors

• Basic heated mirror assembly: $250-$400 parts + labor.
• Mirrors with radar and auto-dimming: $800-$1,600 total because sensor calibration is required.
• DIY can save the one-hour labor charge (about $100).

Environmental Impact

A broken mirror that contains radars, LEDs, and motors should be recycled through an e-waste program to keep heavy metals and rare-earth magnets out of landfills. Batteries in key fob approach lights are also recyclable.

Frequently Asked Questions

Q: How do I turn on my heated side mirror?
A: Press the rear-window defogger button; the mirror heaters run with it.

Q: Does every Outback have Blind-Spot Detection lights in the mirror?
A: Only trims equipped with Subaru's BSD system include the amber warning icon on the mirror glass.

Q: Will a Legacy mirror fit my Outback?
A: Often yes for the same generation, but match the wiring because options like radar or turn signals vary.

Q: Why is my mirror shaking while I drive?
A: Some 2024 models have a known vibration issue under legal review; check for service campaigns.

Q: Can I fold my mirrors automatically?
A: On 2025 Outback Touring and Limited trims, mirrors fold in when you lock the doors.

Q: Do mirrors need calibration after replacement?
A: Yes if your mirror contains radar or cameras; a scan tool is required to relearn blind-spot zones.
