Key points in one paragraph
The Toyota Camry uses one or two electric fans behind the radiator to pull cool air through the fins when the car is moving slowly or idling. They switch on through fuses, relays, sensors, and the engine-control computer. When the system works, engine and A/C temperatures stay in the safe zone. When it fails, you'll see rising temp gauges, weak A/C at a stop, or steam. Most faults trace back to blown fuses, worn relays, seized motors, or damaged wiring. Regular checks and fast fixes prevent warped cylinder heads and pricey repairs. Expect labor to take 1-3 hours, part prices that vary by model year, and small mounting-bolt torque around 5 N·m (44 in-lb) on the 2AZ-FE engine (QCLT Share).

New Section:

Cooling Fan Job

A liquid-cooled engine turns heat-laden coolant over to the radiator; the fan then drags outside air through the fins to shed that heat (Wikipedia, Wikipedia). Front-wheel-drive cars like the Camry rely on electric fans because a belt-driven fan would blow sideways (Wikipedia).

New Section:

How It Works

1. Sensor call-up - the coolant-temperature sensor tells the ECU when coolant nears 203-215 °F.
2. Fuse → relay → motor - 50 A "FAN" fuse feeds a relay in the under-hood box; the relay energizes the fan motor circuit (StartMyCar, Toyota Club).
3. Two-speed logic - many Camrys run both a "radiator" and a "condenser" fan; low speed with A/C on, high speed under heavy load .
4. Shut-off - as the coolant cools, the ECU drops the ground side of the relay and the fan coasts to a stop.

New Section:

Failure Signs

• Gauge climbs past halfway, especially in traffic (Car Talk Community)
• A/C warm at idle, cold at highway speed
• Fan blades still when the engine is hot and A/C is on (2CarPros)
• Blown 50 A FAN fuse or melted relay socket (StartMyCar)
• Burning-plastic smell from a locked motor

New Section:

Quick Checks

1. Listen/Look - pop the hood; a working fan makes a smooth "whoosh."
2. Scan for codes - some Camrys log P0480/P0481 (fan control) when the relay sticks (CarComplaints.com).
3. Jumper the relay - on XV50 models the relay is beside the battery; a paperclip test confirms power to the motor (YouTube).
4. Spin test - engine off, blades should spin freely by hand.
5. Voltage drop - more than 0.2 V across a ground means corrosion in the harness (2CarPros).

New Section:

Replacement Steps

• Remove upper radiator support and shroud bolts.
• Unplug both motors; press side tabs to avoid breaking housings.
• Lift the fan assembly straight up to clear the lower pegs.
• Transfer rubber isolators; torque small fasteners to ~5 N·m (QCLT Share).
• Bleed coolant if the radiator hoses were removed.

New Section:

Year Compatibility

← scroll table horizontally →

Most assemblies interchange within a generation but confirm plug shape and blade count.

New Section:

Maintenance Tips

• Blow out fins every 12 months to keep airflow high (Wikipedia).
• Flush coolant per the manual so mineral scale does not insulate the radiator.
• Check relays whenever you replace a battery; heat cycles weaken solder joints (Car Talk Community).
• Never spray high-pressure water directly at the motor seals.

New Section:

Costs & Labor

• Average motor-only swap: US $954-$1,067 (RepairPal.com)
• Whole fan assembly: US $2,416-$2,655 on late XV70 hybrids due to brushless design (RepairPal.com)
• DIY savings run 30-50 % if you already own a basic socket set.

New Section:

Upgrades & Performance

Aftermarket high-CFM fans move more air but draw extra amps; check alternator output before installing. A 2,000 CFM electric fan will usually keep a 400-hp engine cool on the street (GC Cooling).

New Section:

Safety & Legal Notes

Toyota issued TSB T-SB-0205-12 for 2010-2011 Camry 2.5 L cars because fan-blade separation could trigger high engine temps or weak A/C; dealers updated the ECM and replaced fans where needed . Always disconnect the negative battery cable before touching the fan harness; the ECU can spin the fan any time, even with the key off.

New Section:

Q: What temperature should the Camry fan start?
A: Most models switch on near 203 °F and turn off around 185 °F (Wikipedia).

Q: Does the fan run with the A/C?
A: Yes; the ECU turns on at least one fan whenever the A/C clutch engages to keep refrigerant pressure stable .

Q: Where is the cooling-fan fuse?
A: On 2012-2017 cars it's a 50-amp "FAN" cartridge in the main under-hood fuse block (StartMyCar).

Q: Can I drive if the fan is broken?
A: Only for a very short distance; without airflow the engine can overheat quickly in traffic (RepairPal.com).

Q: Why does the gauge read hot but the fan spins?
A: A sticky thermostat or an air pocket can mimic fan failure. Bleed the system and test the thermostat before replacing parts (Car Talk Community).

Q: My fan only works on high; causes?
A: Likely the low-speed resistor or one of the two relays is burned out (2CarPros).

Q: Fan works with A/C but not without?
A: The ECU-controlled relay for the engine temp circuit may be open while the A/C relay is still good (YouTube).

Q: What size are the fan-mount bolts?
A: M6 bolts torqued to roughly 5 N·m (44 in-lb) on 2AZ-FE and most later engines (QCLT Share).

Q: Are hybrid-battery fans the same as radiator fans?
A: No. Hybrids have a separate small blower just for the traction-battery pack (CarComplaints.com).

Q: How long do fan motors last?
A: Many last the life of the vehicle, but dust, coolant leaks, and high heat can shorten life to 8-10 years (RepairPal.com).

Q: Can bad fans trigger a check-engine light?
A: Yes-codes P0480, P0481, and sometimes P0117 for coolant-temp circuit (2CarPros).

Q: Do I need special tools to swap the fan assembly?
A: Basic metric sockets and a trim-clip puller are enough for most Camry generations (iFixit).
