Buy Ford Crown Victoria Disc Brake Calipers

The disc-brake caliper is the "hand" that squeezes the brake pads against the spinning rotor to slow your Crown Vic. Fluid from the master cylinder pushes one or two pistons inside the caliper body; that force turns into friction and safely stops the sedan link. All Crown Victorias (1992-2011) have four-wheel discs, but 1998-up cars added larger rotors and dual-piston front grippers for shorter stops, a change shared with Police Interceptor (P71) packages link.

• 1992-1997: Single-piston 48 mm front caliper; 38 mm rear.
• 1998-2002: Dual-piston 44 mm front clamp; same rear.
• 2003-2011 (all trims, incl. P71): Revised steering knuckle but caliper bolt spacing unchanged, so earlier '98-02 dual-piston units still bolt on link.
• Interchange: Front and rear calipers also swap with Mercury Grand Marquis and Lincoln Town Car of the same years link.
• Common upgrade: Adapter brackets let you slide the stock caliper outward and pair it with a 14-inch Mustang rotor for ~20 % more heat capacity without changing hydraulic parts link (Range Industries).

Inside the caliper, a phenolic or steel piston rides on square-cut seals. When you press the pedal, brake fluid pushes the piston(s) out, pinching pads against the rotor. Release the pedal and the seal flexes back, pulling the piston a hair away so the rotor spins freely link. On rear wheels, an extra screw-type mechanism also clamps the rotor for the parking brake link.

← scroll table horizontally →

1. Flush DOT 3/4 fluid every two years to keep water out of the system link.
2. Torque specs matter: Front caliper-to-anchor bolts 32 lb-ft (44 N·m); anchor-to-knuckle bolts 118 lb-ft (160 N·m) link.
3. Clean and lube slide pins with silicone-based grease every pad change link.
4. Inspect piston material: phenolic pistons resist heat soak, while steel pistons tolerate rough service better link (Crown Vic).

1. Safety first: Chock wheels, wear goggles, loosen lug nuts.
2. Remove clamp: Unbolt the two 13 mm slide pins; hang the caliper with wire.
3. Swap pads/rotor: Slide off bracket, pull old rotor.
4. Compress piston: Use a C-clamp or cube tool; rear pistons twist in.
5. Re-install & torque bolts to spec (see earlier).
6. Bleed brakes and top off fluid; pedal should feel firm link.
7. Bed pads: Five smooth 40-to-10 mph stops cool-down cycles prevent glazing.

• Bigger rotor kits shift the factory clamp outward for extra leverage, useful on heavy taxi or canyon-drive builds link (Range Industries).
• High-friction pads give stronger "bite" but may dust more; Police pads use a more aggressive compound link (Crown Vic).
• Steel-braided hoses hold pressure under heat and sharpen pedal feel; ensure hoses meet DOT FMVSS No. 135 standards link.

Federal Motor Vehicle Safety Standard 135 sets minimum stopping-distance and hydraulic-integrity rules for passenger-car brakes, including caliper design link. Always torque hardware and use new copper washers on banjo bolts to avoid leaks that could violate the standard.

Every pad scrape leaves a tiny dust cloud; copper and other metals can wash into streams. The Copper-Free Brake Initiative aims to cut copper in brake friction material to < 0.5 % by 2025 link. Choosing low-copper pads and recycling old calipers (they're 100 % recyclable iron) help protect waterways link.

Q: How do I know my Crown Vic's brake clamp is bad?
A: Look for pulling, uneven pad wear, or a wheel that stays hot after a short trip link.

Q: Can I mix phenolic and steel pistons left vs. right?
A: Yes, but Ford recommends matching sides for balanced heat transfer link (Crown Vic).

Q: What size wrench for the bleeder screw?
A: Most 1998-2011 clamps use an 8 mm bleeder; clean the nipple before loosening link.

Q: Do Police Interceptor calipers fit my civilian LX?
A: Yes-front dual-piston clamps share the same bolt pattern; just ensure you have 16-inch wheels for rotor clearance link (Crown Vic).

Q: What torque for the caliper bolts?
A: Slide pins 32 lb-ft (44 N·m); bracket bolts 118 lb-ft (160 N·m) link.

Q: Do I need to bleed after simply changing pads?
A: Not if you don't open the fluid line and you compress the piston slowly-but if the pedal feels spongy, perform a quick bleed link.

Q: Can I paint my calipers?
A: Yes. Use high-temp enamel over a degreased surface; avoid the piston seal and slide boots. Painted clamps can cut rust and add style.

Q: What brake fluid works best?
A: DOT 3 is factory spec; DOT 4 resists heat better but must be flushed more often; never mix with silicone DOT 5.

Q: How long should a rebuilt caliper last?
A: With fresh fluid and proper lube, 100,000 miles is common; many taxi fleets see 150k before replacement link (Crown Vic).

By following these tips, choosing quality friction material, and watching for early warning signs, you can keep your Ford Crown Victoria's disc-brake calipers-those trusty stopping clamps-in top shape for years to come.
