Quick Summary

The Lexus ES300 oxygen sensor-often called an O2 sensor, air-fuel ratio sensor, or lambda probe-sits in the exhaust pipe and tells the engine computer how much oxygen is in the exhaust. The computer uses that signal to keep fuel burn clean and efficient. Healthy sensors help the ES300 pass emissions tests, save gas, and protect the catalytic converter. (Cars.com, Denso)

New Section:

What the Sensor Does

Inside the sensor is a tiny ceramic tip that gets hot and produces a voltage when exhaust flows past it. A high voltage means the engine is running rich (too much fuel); a low voltage means it's lean (too much air). The engine control unit (ECU) adjusts fuel in milliseconds to stay near the ideal 14.7-to-1 air-fuel ratio, also called stoichiometric. (NGK Spark Plugs, Denso)

New Section:

Location & Types

Most 1992-2001 ES300s with the 3.0 L 1MZ-FE V-6 have four sensors: two air-fuel sensors upstream (one for each bank) and two traditional O2 sensors downstream, after the catalytic converters. Earlier 1992-1996 models may use only two sensors. They screw into the exhaust manifold or the pipe just ahead and behind the converters. (Club Lexus, Lexus Owners Club of North America)

New Section:

Why It Matters

A working O2 sensor can boost fuel economy by up to 40 %, according to the Car Care Council. It also keeps toxic gases low so the ES300 meets clean-air rules listed by the U.S. EPA.

New Section:

Signs of Trouble

• Check-engine light with codes P0130-P0161
• Drop in miles per gallon
• Rough idle or engine stumble
• Smell of rotten eggs from the exhaust
• Failed emissions test
  These symptoms appear because the ECU can no longer trim fuel correctly. (Cars.com, Club Lexus)

New Section:

Diagnosing the Sensor

1. Read codes with an OBD-II scanner (P0135 is common for "heater circuit" on Bank 1 Sensor 1).
2. Look at live data. A good upstream sensor will switch rapidly between about 0.1 V and 0.9 V at idle. (NGK Spark Plugs)
3. Check heater resistance (often 11-16 Ω when cool). (NGK Spark Plugs)
4. Spray propane into the intake; voltage should jump high if the sensor reacts.

New Section:

Replacement Basics

Warm engine parts can burn-work on a cool exhaust.

1. Unplug the harness.
2. Remove the old sensor with an O2-sensor socket. A little penetrating oil helps.
3. Lightly coat the new threads with anti-seize (avoid the tip).
4. Torque to 29 ft-lb (40 N·m) unless the service manual says differently.
   The NGK installation guide shows each step clearly for DIYers. Detailed how-to pictures for the rear bank sit on this helpful ToyotaNation forum post.

New Section:

Service Interval

Toyota recommends inspection every 60 000 miles and replacement around 90 000-120 000 miles, or sooner if problems show. Many owners report upstream sensors failing first, while downstream units often survive a bit longer. (Club Lexus)

New Section:

Cost Snapshot

Labor is usually one hour per sensor. Typical U.S. shop quotes run $220-$430 per sensor, depending on location and sensor type. A cost breakdown is available from RepairPal's estimator.

New Section:

Environmental Impact

A dead lambda probe can raise carbon-monoxide and unburned hydrocarbon output by several times, says an EPA durability study. (EPA NEST) Replacing a faulty sensor keeps your catalytic converter safe and cuts greenhouse gases, helping meet the clean-air goals described in Denso's emission-control brief. (Denso)

New Section:

Compatibility Notes

← scroll table horizontally →

Sensor part numbers differ for California-spec vehicles with stricter emissions rules-double-check the under-hood label. (Lexus Owners Club of North America)

New Section:

Q: What does "Bank 1 Sensor 1" mean?
A: Bank 1 is the side of the engine with cylinder 1; Sensor 1 is the first sensor before the catalytic converter.

Q: Can I drive with a bad O2 sensor?
A: The car will run, but it may burn extra fuel and can damage the catalyst if ignored. Fix it soon. (Cars.com)

Q: Will replacing the sensor improve gas mileage right away?
A: Yes-many drivers notice mileage go up on the next tank because the ECU can now fine-tune fuel again. (Reddit)

Q: How many sensors does my ES300 have?
A: Most 1997-2003 models have four; earlier years may have two. Check under the car or scan for sensor IDs. (Club Lexus)

Q: Do I need a special socket?
A: A slotted 22 mm (7⁄8-inch) oxygen-sensor socket makes removal easier around the wiring. (NGK Spark Plugs)

Q: Should I disconnect the battery after replacement?
A: Yes-pulling the negative cable for 5 minutes clears any stored fuel trims and lets the ECU relearn quickly. (Toyota Nation)

Q: What causes heater-circuit code P0135?
A: Usually an open heater coil in the sensor or a blown fuse; test resistance to confirm. (Club Lexus)

Q: Do downstream sensors affect fuel trim?
A: Mostly they monitor catalytic-converter health; upstream sensors handle fuel control. (NGK Spark Plugs)

Q: How hot does an oxygen sensor get?
A: Operating temps reach about 650 °F (350 °C); the built-in heater brings it up to temperature quickly. (NGK Spark Plugs)

Q: Is anti-seize always required?
A: Most new sensors ship with a nickel coating on the threads; add a thin film only if instructions call for it. (NGK Spark Plugs)

New Section:

Related Terms

O2 sensor, air-fuel ratio sensor, AF sensor, lambda probe, exhaust gas sensor, AFR sensor, wide-band sensor, heated oxygen sensor (HO2S).

New Section:

Further Reading

• Learn more about basic sensor science at NGK's resource hub.
• Step-by-step DIY photos for the rear bank swap on Toyota and Lexus V-6 engines are on ToyotaNation.
• EPA answers about clean transportation tech can be found here.

By keeping the Lexus ES300 oxygen sensor in top shape, drivers save fuel, cut pollution, and keep their engines running smoothly.
