Detailed specifications and attributes for this part:
| Attribute | Value |
|---|---|
| ABS Tone Ring Included | Yes |
| ABS Tone Ring Tooth Quantity | 48 |
| ABS Tone Ring Type | Window |
| Axle Nut Included | Yes |
| Axle Nut Length | 0.72, 18.3 |
| Axle Nut Socket Size | 1.378, 35 |
| Axle Nut Thread Size | M24x1.5 |
| Axle Nut Type | Hex |
| Boot Color | Black |
| Boot Material | Neoprene |
| Boot Rib Quantity | 3 |
| CV Joints Included | Yes |
| Compressed Length | 24, 609.6 |
| Contains Electronic Components | No |
| Does It Require SDS | No |
| Dynamic Damper Attached | No |
| FAA A1 | When The Replacement Drive Axle Was Installed, The Sensor Ring, Sensor, Or Sensor Wiring On Or Near The Axle Was Damaged, Causing An Erratic Speed Signal To The Abs Module And Setting The Light On. |
| FAA A10 | Never Allow The Cv Drive Axles To Hang Unsupported. This Can Lead To Axle Separation And Damage To The Inner Joint. |
| FAA A11 | The Most Likely Cause Is A Broken Bearing Cage Due To Excessive Torque Load. This Is Typically An Outboard Joint Problem. |
| FAA A2 | The Most Likely Cause Is A Defective Or Worn Outer Cv Drive Axle Joint. It May Be Time To Get It Replaced. |
| FAA A3 | The Most Likely Cause Is The Drive Train Shifting In The Chassis Due To A Broken Engine Mount Or Hardware, Causing Misalignment Of The Cv Drive Axle And Causing The Inner Joint To Bind Or Hang Up. |
| FAA A4 | The Most Likely Problem Is The Outer Cv Drive Axle Boot Has Ruptured, Causing The Grease To Leak Out, Allowing Contamination (water And Dirt) To Enter And Damage The Joint. |
| FAA A5 | The Transaxle Gear Alignment Has Been Lost. On Some Vehicles It Will Be Necessary To Disassemble The Transaxle To Properly Align The Output Gears. Always Remove And Install One Cv Drive Axle At A Time. |
| FAA A6 | No! A Prevailing Torque Lock Nut Should Never Be Reused. Always Discard The Old Nut And Install A New One. |
| FAA A7 | Always Use The Proper Press Type Tool To Remove The Old Stub Shaft. Never Strike The Outer Joint Stub Shaft With A Hammer. It Will Damage The Unit And Possibly Do Damage To The Hub Bearing Assembly. |
| FAA A8 | Never Use An Impact Wrench To Install The Retaining Nut On The Cv Drive Axle. Always Use A Torque Wrench And Torque The Nut To Manufacture's Specifications. |
| FAA A9 | When Replacing Cv Drive Axle Assemblies, Always Install New Transaxle Seals To Avoid Leaking. |
| FAQ Q1 | I Installed A Replacement Cv Drive Axle And Now My Abs Light Is On And Won't Go Out. Why? |
| FAQ Q10 | Can I Let The Cv Drive Axles Hang While I Am Working On The Car? |
| FAQ Q11 | The Wheels Wobble When I Make A Turn. What's The Problem? |
| FAQ Q2 | When I Cut The Wheel Hard And Step On The Gas, I Hear Loud Clicking And Snapping. What's Making That Noise? |
| FAQ Q3 | When I Step On The Gas, I Hear A Loud Thump And Feel A Bad Vibration. What's Wrong? |
| FAQ Q4 | I Hear A Grinding Noise From The Front End While Driving And See Grease On The Chassis And Suspension. What Is Causing This? |
| FAQ Q5 | I Removed Both Cv Drive Axles At The Same Time And Now I Am Having Problems Reinstalling Them. What Can I Do? |
| FAQ Q6 | The Old Cv Drive Axle Has A Locking Style (prevailing Torque) Nut. Should I Reuse It? |
| FAQ Q7 | The Cv Drive Axle Outboard Joint Stub Shaft Is Stuck In The Hub Assembly. What's The Best Way To Remove It? |
| FAQ Q8 | Is It Ok To Use An Impact Hammer To Install The Retaining Nut? |
| FAQ Q9 | When I Replace The Cv Drive Axles, Should I Reuse The Old Seals? |
| Grade Type | Standard |
| Inboard Joint Mount Hole Quantity | 6 |
| Inboard Joint Type | Bolt-on |
| Is Item A Chemical | No |
| Is Or Contains A Battery | No |
| Is Or Contains A Bulb | No |
| Is Prop Sixty Five Affected | No |
| Is The Item CARB Affected | No |
| Outboard Joint Type | Splined |
| Outboard Spline Quantity | 27 |
| Product Condition | New |
| Shaft Diameter | 1.102, 28 |
| Shaft Material | Steel |
| Slip Yoke | No |
| Universal Joints Included | No |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| 2.5i | Convertible | 2003 - 2005 | L6 2.5L | RWD Automatic & Manual |
| 3.0i | Convertible | 2003 - 2005 | L6 3.0L | RWD Automatic & Manual |
⚠️ Important: Please verify your vehicle's year, make, model, and specifications before ordering. If you're unsure about fitment, contact our customer service team for assistance.
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| BMW | 33211226904 |
| BMW | 33211227585 |
| BMW | 33211229300 |
| BMW | 33211229428 |
| BMW | 33211229591 |
Fits Years: 2003 2004 2005
Fits Models: Z4
