Detailed specifications and attributes for this part:
| Attribute | Value |
|---|---|
| Connector Gender | Female |
| Connector Quantity | 1 |
| Connector Shape | Rectangle |
| Contains Electronic Components | No |
| Does It Require SDS | No |
| FAA A1 | Do Not Operate The Motor While It Is Off The Transfer Case. This Can Damage The Motor And Set An Error Code That Must Be Cleared Before The Motor Will Operate Again. Shift The Transfer Case Into The Position Of The Motor To Install. |
| FAA A2 | Yes, The Transfer Case Should Be Manually Shifted Into The Two-wheel Drive Position At The Shift Shaft Before The Installation Of The Replacement Motor. Typically The Positions Are Spring-loaded And Can Be Rotated Manually. |
| FAA A3 | A Crescent Wrench Can Be Used For This Operation. |
| FAA A4 | The Replacement Motor Drive Is Factory-set In The 2 Wheel Drive Position. |
| FAA A5 | This May Be Caused By A Transfer Case Control Module Calibration Issue. Check For Dtc's And Calibration Version ? There May Be A Software Update From The Original Equipment Manufacturer. |
| FAQ Q1 | The Replacement Motor Drive Is In A Different Position, Can I Reposition Before Installing? |
| FAQ Q2 | Can I Install The Replacement Motor If My Transfer Case Motor Failed In 4 Wheel Drive Low Or High? |
| FAQ Q3 | What Tool Can I Use To Manually Shift The Transfer Case Into The Two-wheel Drive Position Before I Install The Replacement Motor? |
| FAQ Q4 | What Drivetrain Position Is The Replacement Motor Drive Placed In? |
| FAQ Q5 | The Service 4wd Light Is On And/or The 4wd Is Inoperative. What Could Cause This Condition? |
| FAQ Q6 | If The Motor Attempts To Shift, But Sounds Weak, Check The Front Axle Lock Actuator. If The Axle Lock Does Not Engage, The Motor Cannot Complete Its Engagement. |
| Gear Of Chain Type | Gear |
| Grade Type | Performance |
| Is Item A Chemical | No |
| Is Or Contains A Battery | No |
| Is Or Contains A Bulb | No |
| Is Prop Sixty Five Affected | No |
| Is The Item CARB Affected | No |
| Mounting Hardware Included | No |
| Mounting Hole Quantity | 4 |
| Product Condition | Remanufactured |
| Shift Operation Type | Electronic |
| Sprocket Tooth Quantity | 13 |
| Terminal Gender | Male |
| Terminal Quantity | 7 |
| Terminal Type | Blade |
| Wire Quantity | 7 |
| Wiring Harness Included | Yes |
| Wiring Harness Length | 13.75, 349.25 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| A | SUV | 2004 - 2007 | L6 4.2L | RWD Automatic |
| B | SUV | 2006 | L6 4.2L | 4WD Automatic |
| B | SUV | 2004 - 2007 | L6 4.2L | RWD Automatic |
| Base | SUV | 2008 | L6 4.2L | 4WD Automatic |
| Base | SUV | 2008 | V8 5.3L | RWD/4WD Automatic |
| Base | SUV | 2003 - 2008 | L6 4.2L | RWD Automatic |
| LS | SUV | 2006 - 2007 | V8 5.3L | RWD/4WD Automatic |
| LS | SUV | 2002 - 2007 | L6 4.2L | RWD/4WD Automatic |
| LT | SUV | 2006 - 2008 | V8 5.3L | RWD/4WD Automatic |
| LT | SUV | 2002 - 2009 | L6 4.2L | RWD/4WD Automatic |
| LTZ | SUV | 2002 - 2003 | L6 4.2L | RWD/4WD Automatic |
| North Face | SUV | 2002 - 2004 | L6 4.2L | RWD/4WD Automatic |
| Q | SUV | 2005 | L6 4.2L | RWD Automatic |
| R | SUV | 2005 | L6 4.2L | RWD Automatic |
| SS | SUV | 2006 - 2009 | V8 6.0L | AWD/RWD Automatic |
⚠️ Important: Please verify your vehicle's year, make, model, and specifications before ordering. If you're unsure about fitment, contact our customer service team for assistance.
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Chevrolet | 88935650 |
| Chevrolet | 88996637 |
| Chevrolet | 89059275 |
Fits Years: 2002 2003 2004 2005 2006 2007 2008 2009
Fits Models: Trailblazer
