| Attribute | Value |
|---|---|
| Automotive Item Weight (lbs) | 1.75488 Lb |
| Connector Gender | Female |
| Connector Quantity | 1 |
| Connector Shape | Square/rectangle |
| Electrical | Yes |
| Filter Included | Yes |
| Fuel Delivery Type | Fuel Injection |
| Fuel Filter Included | Yes |
| Fuel Sending Unit Included | No |
| Fuel Tank Pressure Sensor Included | No |
| Fuel Type | Gas |
| Fuel Type (Fuel Pump) | Gas |
| Gasket Or Seal Included | No, Yes |
| Gasket Or Seal Material | Synthetic Or Nbr Rubber |
| Grade Type (Premium) | Premium |
| Hose Length (Fuel Pump) | 0 Ft |
| Housing Width | 51 Mm |
| In Tank Or External | External |
| In Line Pump | Y |
| Inlet Fitting Thread Size | Quick Connect |
| Inlet Outside Diameter | 14 |
| Inlet Size | 8 Mm |
| Inside Diameter | 6 Mm |
| Lock Ring Included | No |
| Material | Steel |
| Metered | Yes |
| Mounting Hardware Included | No |
| Mounting Type | Bolt On |
| Nozzle Shut Off Valve Included | No |
| Nozzle Type | Fixed |
| Outlet Fitting Thread Size | M14 X 1.5 |
| Outlet Outside Diameter | 14 |
| Outlet Quantity | 1 |
| Port Quantity | 2 |
| Power Cord Length | 0 Ft |
| Power Source | Battery |
| Prop 65 Warning Label Required? | No |
| Pump Design | Mechanical |
| Pump Type | Electric, Mechanical |
| Regulator Included | Yes |
| Rim Shape | Round |
| Seal And Lock Ring Included | No |
| Seal Type | O-ring |
| Self Priming | Yes |
| Static Ground Terminal | No |
| Strainer Included | No |
| Suction Pipe Included | No |
| Terminal Gender | Male |
| Terminal Quantity | 2 |
| Terminal Type | Blade |
| Voltage | 12 V |
| Wire Gauge Measurement | 0 Ga. |
| Wire Harness Included | No |
| Wire Quantity | 0 |
| Wiring Harness Included | No |
| Wiring Harness Length (mm) | 0 Mm |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | SUV | 2020 - 2024 | L4 2.3L Turbo | AWD/RWD Automatic |
| Base | SUV | 2020 - 2023 | V6 3.3L FLEX | AWD/RWD Automatic |
| King Ranch | SUV | 2021 - 2024 | V6 3.0L Turbo | AWD/RWD Automatic |
| Limited | SUV | 2020 - 2024 | L4 2.3L Turbo | AWD/RWD Automatic |
| Limited Hybrid | SUV | 2020 - 2023 | V6 3.3L FULL HYBRID EV-GAS (FHEV) | AWD/RWD Automatic |
| Platinum | SUV | 2022 - 2024 | V6 3.0L Turbo | RWD Automatic |
| Platinum | SUV | 2020 - 2024 | V6 3.0L Turbo | AWD Automatic |
| Platinum Hybrid | SUV | 2021 - 2023 | V6 3.3L FULL HYBRID EV-GAS (FHEV) | AWD/RWD Automatic |
| ST | SUV | 2024 | V6 3.0L Turbo | RWD Automatic |
| ST | SUV | 2020 - 2024 | V6 3.0L Turbo | AWD/4WD Automatic |
| ST-Line | SUV | 2022 - 2024 | L4 2.3L Turbo | AWD/RWD Automatic |
| Timberline | SUV | 2021 - 2024 | L4 2.3L Turbo | AWD Automatic |
| XLT | SUV | 2020 - 2024 | L4 2.3L Turbo | AWD/RWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
Fits Years: 2020 2021 2022 2023 2024
Fits Models: Explorer
