| Attribute | Value |
|---|---|
| Anti Lock Braking System | Yes |
| Anti Lock Braking System Type | Encoder |
| Bearing Generation | Gen 3 |
| Bearing Type | Ball |
| Bolt Circle Diameter | 114.3, 4.5 |
| Brake Pilot Diameter | 2.677, 68 |
| Drive Type | Driven |
| Flange Bolt Hole Quantity | 4 |
| Flange Diameter | 148, 5.83 |
| Flange Included | Yes |
| Flange Offset | 1.693, 43 |
| Flange Quantity | 2 |
| Flange Shape | Offset Trapezoid |
| Knuckle Bolt Circle Diameter | 120, 4.724 |
| Knuckle Bolt Hole Size | 0.47 |
| Knuckle Bolt Thread Pitch | 1.5 |
| Knuckle Pilot Hole Diameter | 3.63, 92.1 |
| Stud Thread Type | Fine |
| Stud Threads Per Inch | 20 |
| Wheel Pilot Diameter | 2.492, 63.3 |
| Wheel Stud Quantity | 5 |
| Wheel Stud Size | 0.5, 12.7 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Limited | Sedan | 2015 - 2019 | V6 3.5L FLEX | AWD/FWD Automatic |
| Limited | Sedan | 2013 - 2017 | L4 2.0L Turbo | AWD/FWD Automatic |
| Limited | Sedan | 2010 - 2019 | V6 3.5L | AWD/FWD Automatic |
| SE | Sedan | 2015 - 2019 | V6 3.5L FLEX | FWD Automatic |
| SE | Sedan | 2013 - 2017 | L4 2.0L Turbo | FWD Automatic |
| SE | Sedan | 2013 - 2014 | L4 2.0L Turbo | AWD Automatic |
| SE | Sedan | 2010 - 2019 | V6 3.5L | FWD Automatic |
| SE | Sedan | 2010 - 2014 | V6 3.5L | AWD Automatic |
| SEL | Sedan | 2015 - 2019 | V6 3.5L FLEX | AWD/FWD Automatic |
| SEL | Sedan | 2013 - 2017 | L4 2.0L Turbo | AWD/FWD Automatic |
| SEL | Sedan | 2010 - 2019 | V6 3.5L | AWD/FWD Automatic |
| SHO | Sedan | 2010 - 2019 | V6 3.5L Turbo | AWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Alltech Automotive | 513275 |
| Autopart International | 1411285209 |
| Carquest | 91-285209 |
| Centric Parts | 401.61000 |
| Centric Parts | 401.61000E |
| Centric Parts | 401.65000 |
| Centric Parts | 401.65000E |
| CRS Automotive | NT513275 |
| DuraGo | 29513275 |
| FAG CA - Archived | 102224 |
| GMB | 7250004 |
| GSP | 114275 |
| Mevotech | H513275 |
| Motorcraft | HUB182 |
| Motorcraft | HUB36 |
| MPA | WH513275 |
| Parts Master | PM513275 |
| Power Train | PT513275 |
| Raybestos Brakes | 713275 |
| SKF | BR930742 |
| SKF | BR930919 |
| Timken | HA590261 |
| WJB | WA513275 |
Fits Years: 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019
Fits Models: Taurus
