| Attribute | Value |
|---|---|
| Center Electrode Core Material | Copper |
| Center Electrode Design | Fine Wire |
| Center Electrode Insulator Tip Projection | 0.14, 3.5 |
| Center Electrode Projection | Mid Projection |
| Center Electrode Tip Material | Iridium |
| Electrical Terminal Type | Non-removable Nut |
| Grade Type | Performance |
| Ground Configuration | J-gap |
| Ground Electrode Core Material | Nickel |
| Ground Electrode Quantity | 1 |
| Ground Electrode Tip Design | Standard |
| Ground Electrode Tip Material | Platinum |
| Hex Size | 5/8" (16mm) |
| Insulator Height | 2.07, 52.5 |
| Insulator Material | Ceramic |
| Manufacturer Heat Range | 6 |
| Material Grade | Iridium Platinum |
| Part Number | Iltr6e11 |
| Pre Gap Size | .044, 1.1 |
| Reach | 0.984, 25.0 |
| Resistance | 5000.0 |
| Resistor Type | Yes |
| Seat Type | Tapered |
| Service Number | Iltr6e11 |
| Short Style Spark Plug | No |
| Skirt | No |
| Skirt Length | 0.0 |
| Stock Number | 90117 |
| Thread Diameter | 0.551, 14.0 |
| Washer Included | No |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| L | SUV | 2015 - 2017 | L4 2.4L | FWD Automatic |
| L | SUV | 2015 - 2017 | L4 2.4L FLEX | FWD Automatic |
| LS | SUV | 2012 - 2017 | L4 2.4L FLEX | AWD/FWD Automatic |
| LS | SUV | 2010 - 2017 | L4 2.4L | AWD/FWD Automatic |
| LS | SUV | 2008 - 2009 | V6 3.4L | AWD/FWD Automatic |
| LT | SUV | 2013 - 2017 | V6 3.6L | AWD/FWD Automatic |
| LT | SUV | 2013 - 2017 | V6 3.6L FLEX | AWD/FWD Automatic |
| LT | SUV | 2012 - 2017 | L4 2.4L FLEX | AWD/FWD Automatic |
| LT | SUV | 2011 - 2012 | V6 3.0L FLEX | AWD/FWD Automatic |
| LT | SUV | 2010 - 2017 | L4 2.4L | AWD/FWD Automatic |
| LT | SUV | 2010, 2012 | V6 3.0L | AWD/FWD Automatic |
| LT | SUV | 2008 - 2009 | V6 3.4L | AWD/FWD Automatic |
| LTZ | SUV | 2013 - 2016 | V6 3.6L | AWD/FWD Automatic |
| LTZ | SUV | 2013 - 2016 | V6 3.6L FLEX | AWD/FWD Automatic |
| LTZ | SUV | 2012 - 2016 | L4 2.4L FLEX | AWD/FWD Automatic |
| LTZ | SUV | 2011 - 2012 | V6 3.0L FLEX | AWD/FWD Automatic |
| LTZ | SUV | 2010 - 2016 | L4 2.4L | AWD/FWD Automatic |
| LTZ | SUV | 2010, 2012 | V6 3.0L | AWD/FWD Automatic |
| LTZ | SUV | 2008 - 2009 | V6 3.4L | AWD/FWD Automatic |
| Premier | SUV | 2017 | L4 2.4L | AWD/FWD Automatic |
| Premier | SUV | 2017 | L4 2.4L FLEX | AWD/FWD Automatic |
| Premier | SUV | 2017 | V6 3.6L | AWD/FWD Automatic |
| Premier | SUV | 2017 | V6 3.6L FLEX | AWD/FWD Automatic |
| Sport | SUV | 2008 - 2009 | V6 3.6L | AWD/FWD Automatic |
