| Attribute | Value |
|---|---|
| Center Electrode Core Material | Copper |
| Center Electrode Design | Fine Wire |
| Center Electrode Insulator Tip Projection | 0.20, 5.0 |
| Center Electrode Projection | Long Projection |
| Center Electrode Tip Material | Iridium |
| Electrical Terminal Type | Non-removable Nut |
| Grade Type | Performance |
| Ground Configuration | J-gap |
| Ground Electrode Core Material | Nickel |
| Ground Electrode Quantity | 1 |
| Ground Electrode Tip Design | Standard |
| Ground Electrode Tip Material | Nickel |
| Hex Size | 5/8" (16mm) |
| Insulator Height | 1.99, 50.5 |
| Insulator Material | Ceramic |
| Manufacturer Heat Range | 5 |
| Material Grade | Iridium |
| Part Number | Lzfr5ci-11 |
| Pre Gap Size | .044, 1.1 |
| Reach | 1.043, 26.5 |
| Resistance | 5000.0 |
| Resistor Type | Yes |
| Seat Type | Flat |
| Service Number | Lzfr5ci-11 |
| Short Style Spark Plug | No |
| Skirt | No |
| Skirt Length | 0.0 |
| Stock Number | 92145 |
| Thread Diameter | 0.551, 14.0 |
| Washer Included | Yes |
| Washer Type | Crush |
This part fits the following vehicles:
This is a universal part that fits 1,179 vehicle configurations across 5 makes.
