| Attribute | Value |
|---|---|
| Center Electrode Core Material | Copper |
| Center Electrode Design | Fine Wire |
| Center Electrode Insulator Tip Projection | 0.12, 3.0 |
| Center Electrode Projection | Mid Projection |
| Center Electrode Tip Material | Iridium |
| Electrical Terminal Type | Non-removable Nut |
| Grade Type | Performance |
| Ground Configuration | J-gap |
| Ground Electrode Core Material | Nickel |
| Ground Electrode Quantity | 1 |
| Ground Electrode Tip Design | Taper Cut |
| Ground Electrode Tip Material | Nickel |
| Hex Size | 14mm |
| Insulator Height | 1.93, 49.0 |
| Insulator Material | Ceramic |
| Manufacturer Heat Range | 7 |
| Material Grade | Iridium |
| Part Number | Lkar7bix-11s |
| Pre Gap Size | .044, 1.1 |
| Reach | 1.043, 26.5 |
| Resistance | 5000.0 |
| Resistor Type | Yes |
| Seat Type | Flat |
| Service Number | Lkar7bix-11s |
| Short Style Spark Plug | No |
| Skirt | No |
| Skirt Length | 0.0 |
| Stock Number | 93501 |
| Thread Diameter | 0.472, 12.0 |
| Washer Included | Yes |
| Washer Type | Crush |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| 100th Anniversary Edition | Sedan | 2021 | L4 2.5L Turbo | AWD/FWD Automatic |
| 2.0 | Sedan | 2021 - 2022 | L4 2.0L | FWD Automatic |
| 2.5 Carbon Turbo | Sedan | 2024 | L4 2.5L Turbo | AWD Automatic |
| 2.5 S | Hatchback | 2021 - 2023 | L4 2.5L | FWD Automatic |
| 2.5 S | Hatchback | 2021 | L4 2.5L | FWD Manual |
| 2.5 S | Sedan | 2021 - 2024 | L4 2.5L | FWD Automatic |
| 2.5 S | Sedan | 2021 | L4 2.5L | FWD Manual |
| 2.5 Turbo | Hatchback | 2021 - 2023 | L4 2.5L Turbo | AWD Automatic |
| 2.5 Turbo | Sedan | 2021 - 2023 | L4 2.5L Turbo | AWD Automatic |
| 2.5 Turbo Premium Plus | Hatchback | 2021 - 2024 | L4 2.5L Turbo | AWD Automatic |
| 2.5 Turbo Premium Plus | Sedan | 2021 - 2024 | L4 2.5L Turbo | AWD Automatic |
| Base | Hatchback | 2019 - 2020 | L4 2.5L | AWD/FWD Automatic & Manual |
| Base | Sedan | 2019 - 2020 | L4 2.5L | AWD/FWD Automatic & Manual |
| Carbon Edition | Hatchback | 2023 - 2024 | L4 2.5L | AWD Automatic |
| Carbon Edition | Hatchback | 2023 | L4 2.5L Turbo | AWD Automatic |
| Carbon Edition | Hatchback | 2022 - 2023 | L4 2.5L | FWD Automatic |
| Carbon Edition | Sedan | 2023 - 2024 | L4 2.5L | AWD Automatic |
| Carbon Edition | Sedan | 2023 | L4 2.5L Turbo | AWD Automatic |
| Carbon Edition | Sedan | 2022 - 2023 | L4 2.5L | FWD Automatic |
| G | Sedan | 2016 - 2018 | L4 2.0L | FWD Manual |
| GS | Sedan | 2019 - 2022 | L4 2.0L | AWD Automatic |
| GS | Sedan | 2019 - 2021 | L4 2.0L | AWD Manual |
| GS | Sedan | 2019 - 2022, 2024 | L4 2.5L | AWD/FWD Automatic |
| GS | Sedan | 2019 - 2021 | L4 2.5L | AWD/FWD Manual |
| GS | Sedan | 2012, 2014 - 2022 | L4 2.0L | FWD Automatic |
| GS | Sedan | 2012, 2014 - 2021 | L4 2.0L | FWD Manual |
| GS-SKY | Sedan | 2012 - 2013 | L4 2.0L | FWD Automatic & Manual |
| GT | Sedan | 2021 - 2024 | L4 2.5L Turbo | AWD/FWD Automatic |
| GT | Sedan | 2019 - 2024 | L4 2.5L | AWD Automatic |
| GT | Sedan | 2012 - 2024 | L4 2.5L | FWD Automatic |
| GT | Sedan | 2012 - 2013 | L4 2.5L | FWD Manual |
| GX | Sedan | 2024 | L4 2.5L | FWD Automatic |
| GX | Sedan | 2012 - 2023 | L4 2.0L | FWD Automatic & Manual |
| Grand Touring | Hatchback | 2017 - 2018 | L4 2.5L | FWD Automatic & Manual |
| Grand Touring | Hatchback | 2012 - 2013 | L4 2.3L Turbo | FWD Manual |
| Grand Touring | Sedan | 2017 - 2018 | L4 2.5L | FWD Automatic & Manual |
| I Sport | Hatchback | 2019 - 2024 | L4 2.5L | FWD Automatic & Manual |
| I Sport | Hatchback | 2014 - 2016, 2022 - 2024 | L4 2.0L | FWD Automatic & Manual |
| I Sport | Sedan | 2019 - 2024 | L4 2.5L | FWD Automatic & Manual |
| I Sport | Sedan | 2014 - 2016, 2022 - 2024 | L4 2.0L | FWD Automatic & Manual |
| I Touring | Hatchback | 2017 - 2018 | L4 2.5L | FWD Automatic & Manual |
| I Touring | Hatchback | 2014 - 2016 | L4 2.0L | FWD Automatic & Manual |
| I Touring | Sedan | 2017 - 2018 | L4 2.5L | FWD Automatic & Manual |
| I Touring | Sedan | 2012 - 2016 | L4 2.0L | FWD Automatic & Manual |
| Mazdaspeed | Hatchback | 2012 - 2013 | L4 2.3L Turbo | FWD Manual |
| Preferred | Hatchback | 2020 - 2024 | L4 2.5L | AWD/FWD Automatic |
| Preferred | Sedan | 2020 - 2024 | L4 2.5L | AWD/FWD Automatic |
| Premium | Hatchback | 2020 - 2024 | L4 2.5L | AWD/FWD Manual |
| Premium | Hatchback | 2020 - 2023 | L4 2.5L | AWD/FWD Automatic |
| Premium | Sedan | 2020 - 2023 | L4 2.5L | AWD/FWD Automatic & Manual |
| S | Hatchback | 2012 - 2018 | L4 2.5L | FWD Automatic |
| S | Hatchback | 2012 - 2013, 2015 - 2018 | L4 2.5L | FWD Manual |
| S | Sedan | 2012 - 2018 | L4 2.5L | FWD Automatic |
| S | Sedan | 2012 - 2013, 2015 - 2018 | L4 2.5L | FWD Manual |
| SE | Sedan | 2018 | L4 2.0L | FWD Automatic |
| Select | Hatchback | 2021 - 2023 | L4 2.5L | AWD/FWD Automatic |
| Select | Sedan | 2020 - 2023 | L4 2.5L | AWD/FWD Automatic |
| Select Sport | Hatchback | 2024 | L4 2.5L | AWD/FWD Automatic |
| Select Sport | Sedan | 2024 | L4 2.5L | AWD/FWD Automatic |
| Signature | Hatchback | 2023 | L4 2.5L Turbo | FWD Automatic |
| Signature | Hatchback | 2021 - 2024 | L4 2.5L Turbo | AWD Automatic |
| Signature | Sedan | 2023 | L4 2.5L Turbo | FWD Automatic |
| Signature | Sedan | 2022 - 2024 | L4 2.5L Turbo | AWD Automatic |
| Sport | Hatchback | 2017 - 2018 | L4 2.0L | FWD Automatic & Manual |
| Sport | Sedan | 2017 - 2018 | L4 2.0L | FWD Automatic & Manual |
| Touring | Hatchback | 2017 | L4 2.0L | FWD Automatic & Manual |
| Touring | Hatchback | 2017 - 2018 | L4 2.5L | FWD Automatic & Manual |
| Touring | Sedan | 2017 | L4 2.0L | FWD Automatic & Manual |
| Touring | Sedan | 2017 - 2018 | L4 2.5L | FWD Automatic & Manual |
| i | Hatchback | 2012 - 2013 | L4 2.0L | FWD Automatic & Manual |
| i | Sedan | 2019 - 2024 | L4 2.5L | FWD Automatic & Manual |
| i | Sedan | 2012 - 2018 | L4 2.0L | FWD Automatic & Manual |
| i Grand Touring | Hatchback | 2019 - 2024 | L4 2.5L | FWD Automatic |
| i Grand Touring | Hatchback | 2014 - 2016 | L4 2.0L | FWD Automatic & Manual |
| i Grand Touring | Sedan | 2019 - 2024 | L4 2.5L | FWD Automatic |
| i Grand Touring | Sedan | 2014 - 2016 | L4 2.0L | FWD Automatic & Manual |
| i SV | Sedan | 2014 - 2015 | L4 2.0L | FWD Automatic & Manual |
| s Grand Touring | Hatchback | 2021 | L4 2.5L Turbo | AWD Automatic |
| s Grand Touring | Hatchback | 2015 - 2016 | L4 2.5L | FWD Manual |
| s Grand Touring | Hatchback | 2014 - 2018 | L4 2.5L | FWD Automatic |
| s Grand Touring | Sedan | 2015 - 2016 | L4 2.5L | FWD Manual |
| s Grand Touring | Sedan | 2014 - 2018 | L4 2.5L | FWD Automatic |
| s Touring | Hatchback | 2015 | L4 2.5L | FWD Manual |
| s Touring | Hatchback | 2014 - 2016 | L4 2.5L | FWD Automatic |
| s Touring | Sedan | 2015 | L4 2.5L | FWD Manual |
| s Touring | Sedan | 2014 - 2016 | L4 2.5L | FWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Omnicraft | QSP7 |
Fits Years: 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 2022 2023 2024
Fits Models: 3
Keep your Mazda 3's Skyactiv engine running efficiently with the right set of new aftermarket spark plugs.
